Galvanized / Epoxy Razor Blade Barbed Wire BTO-30 Blade Style Industry Use
Galvanized/Epoxy/Electrophoretic/Stainless Steel BTO-30 Blade Style Razor Barbed Wire
Material: Galvanized Steel Sheet and wire or Stainless Steel Sheet and Wire, PVC(Epoxy), Electrophoretic
1. Galvanized Steel Sheet and Wire
① Hot dipped galvanzied steel sheet with electric galvanized wire
② Hot dipped galvanized steel sheet with Hot dipped Galvanized wire
③ High galvanized steel sheet with high galvanized wire
2. Stainless Steel Sheet and Wire
430,304, 316, 316L
BTO-30 Razor Blade Specification
Razor Blade Style:BTO-30
Razor Thickness:0.5±0.05mm
Inner wire Dia.: 2.5±0.1mm
Razor Barb Length: 2.5±0.1mm
Razor Barb Spacing: 45±1mm
| Reference No. | Thickness | Wire diameter | Barbe length | Barbe length | Barbe spacing |
| BTO-10 | 0.5 +/- 0.05 | 2.5 +/- 0.1 | 10 +/- 1 | 13 +/- 1 | 26 +/- 1 |
| BTO-12 | 0.5 +/- 0.05 | 2.5 +/- 0.1 | 15 +/- 1 | 15 +/- 1 | 26 +/- 1 |
| BTO-18 | 0.5 +/- 0.05 | 2.5 +/- 0.1 | 18 +/- 1 | 15 +/- 1 | 33 +/- 1 |
| BTO-22 | 0.5 +/- 0.05 | 2.5 +/- 0.1 | 22 +/- 1 | 15 +/- 1 | 34 +/- 1 |
| BTO-28 | 0.5 +/- 0.05 | 2.5 | 28 | 15 | 45 +/- 1 |
| BTO-30 | 0.5 +/- 0.05 | 2.5 | 30 | 18 | 45 +/- 1 |
| CBT-60 | 0.6+/- 0.05 | 2.5 +/- 0.1 | 60 +/- 2 | 32 +/- 1 | 100 +/- 2 |
| CBT-65 | 0.6 +/- 0.05 | 2.5 +/- 0.1 | 65 +/- 2 | 21 +/- 1 | 100 +/- 2 |
our factory supply free sample for you to check the quality
| Outside Diameter | No. of Loops | Standard Length per Coil | Type | Notes |
| 450mm | 33 | 8M | CBT-65 | Single coil |
| 500mm | 41 | 10M | CBT-65 | Single coil |
| 700mm | 41 | 10M | CBT-65 | Single coil |
| 960mm | 53 | 13M | CBT-65 | Single coil |
| 500mm | 102 | 16M | BTO-10.15.22 | Cross type |
| 600mm | 86 | 14M | BTO-10.15.22 | Cross type |
| 700mm | 72 | 12M | BTO-10.15.22 | Cross type |
| 800mm | 64 | 10M | BTO-10.15.22 | Cross type |
| 960mm | 52 | 9M | BTO-10.15.22 | Cross type |
Razor Type Wire Specification
The lengh and the diameter of the coil can be desighed according to the customers' need.
Conventional Weight and Diameter of per coil Razor: 500mmx10kg/coil which cover meter 10 meters (when spacing meter is 0.35-0.4meter)
Package:
1. Inner waterproof paper with woven bag outside, 50 coils be a bundle with strips
2. Be packed into carton
3. 50coils be a pallet.
4. as customers' requirement
It plays the role of protection in mines, gardens and apartments, frontier and sentry defence, and enclosure of prisons.
Anping TaiYe Wire Mesh Products Co.,LTD is a professional (ISO9001:2008 certificated) manufacturer and exporter of series wire mesh products. This company is located in North Industrial Park of Anping which is well known as Wire Mesh Land of China, enjoys convenient transport condition being close to Beijing, Capital City of China and Tianjin, one of the most important seaport in North China.
Any question kindly contact our sales manager Rill.
Skype is rill1990,
email is rill90@hotmail.com or rill@aptaiye.com,
mob or weichat is 86 18731838063 or RillJI.
Glad to provide professional service for u.
