Industry Security Single Coil Razor Wire Hot Dipped Galvanized Razor Edge Wire
Hot Dipped Galvanized Razor Edge Wire BTO22 Single Coil Used In Industry Security
1. Chemical Tests
Element Razor ( Req %) Conform Core Wire (Req %) Conform
| C | 0.14-0.21 | 0.85-0.95 |
| Si | 0.09-1 | 0.10-0.23 |
| Mn | 0.4-0.5 | 0.38 |
| Cr | 0.3-0.4 | 0.30 |
| Ni | 0.36-0.4 | 0.35 |
| Cu | ≤0.06 | ≤0.06 |
| Fe | 98.25 | 97.57 |
2. Mechanical / Physical quantities
| Sr | Properties | Req Limits Conform |
| a | Corrosion/rust resisting | Min 5 years |
| b | Hot Dipped Galvanized Wire & Blade | |
| c | Razor Zn surface coating(g/m2) | 80 |
| d | Core Wire Zn coating thickness(μm) | 8-10 |
| e | Core Wire tensile strength(MPa) | 1430-1450 |
| f | Core Wire Hardness(HV) | ≤410 |
| g | Razor Hardness(HV) | ≤116 |
3. Physical measurements
| Sr | Properties | Req Limits |
| a | Blade Thickness(mm) | 0.5±0.05 |
| b | Core Wire Dia(mm) | 2.5±0.01 |
| c | Barb Length(mm) | 22±1 |
| d | Barb Width(mm) | 15±1 |
| e | Barb Spacing(mm) | 35±1 |
| f | Loops/Coil (nos) | 288 |
| g | Coi Dia(mm) | 700±5 |
| h | CoilLength(m) | 70 |
| i | Weight/Coil(kg) | 65±2 |
Razor wire usage:
maily serves in protecting of grass boundary, railway, highway and also widely used in military, jail and other national security organizations, and industry, agriculture, animal husbandry, dwelling house, also used as fence for cottage as society fence and other private buildings.
Packing Details:
1. 3kg - 15kg per roll,liner waterproof paper ,outside weaving bag,
2. 300-500kg per bundle ,
3. use carton box,using pallet
4. according to customer requirements
