PVC Coated Galvanized BTO 22 Razor Wire Mesh Fence Single Twist Method
Price:
To be negotiated
MOQ:
200 Rolls
Delivery Time:
Within 15 days or as your need
Brand:
Taiye
Product Description
Galvanised Barbed Razor Wire , Rust Resistance Concertina Razor Wire For Prison
Product Description
Razor barbed wire is also named concertina coils or razor type barbed wire. It is a kind
of modern security fencing materials with better protection and fencing strength made
of hot-dipped galvanized steel sheets or stainless steel sheets. With beautiful and sharp
blades and strong core wire, razor barbed wire has the features of secure fencing, easy
installation, age resistance and other properties.
1. Material: High carbon steel, galvanized steel sheet and wire, stainless steel sheet
and wire. Usually, hot dipped galvanized razor barbed wire is popular in the market.
2.Razor Type: BTO-10, BTO-12, BTO-18, BTO-22, BTO-30,CBT-60,CBT-65.
3.Razor wire types: straight line razor wire, single coil concertina wire, double coil wire,
welded razor mesh fence.
of modern security fencing materials with better protection and fencing strength made
of hot-dipped galvanized steel sheets or stainless steel sheets. With beautiful and sharp
blades and strong core wire, razor barbed wire has the features of secure fencing, easy
installation, age resistance and other properties.
1. Material: High carbon steel, galvanized steel sheet and wire, stainless steel sheet
and wire. Usually, hot dipped galvanized razor barbed wire is popular in the market.
2.Razor Type: BTO-10, BTO-12, BTO-18, BTO-22, BTO-30,CBT-60,CBT-65.
3.Razor wire types: straight line razor wire, single coil concertina wire, double coil wire,
welded razor mesh fence.
Specification
|
Reference
Number |
Thickness
|
Wire Dia
|
Barb
Length |
Barb
Width |
Barb
spacing |
|
BTO-10
|
0.5±0.05
|
2.5±0.1
|
10±1
|
13±1
|
25±1
|
|
BTO-12
|
0.5±0.05
|
2.5±0.1
|
12±1
|
15±1
|
25±1
|
|
BTO-18
|
0.5±0.05
|
2.5±0.1
|
18±1
|
15±1
|
35±1
|
|
BTO-22
|
0.5±0.05
|
2.5±0.1
|
22±1
|
15±1
|
36±1
|
|
BTO-28
|
0.5±0.05
|
2.5
|
28
|
15
|
46±1
|
|
BTO-30
|
0.5±0.05
|
2.5
|
30
|
18
|
46±1
|
|
CBT-65
|
0.6±0.05
|
2.5±0.1
|
65±2
|
21±1
|
101±2
|
|
Outside Diameter
|
No. of Loops
|
Standard Length per Coil
|
Type
|
Notes
|
|
450mm
|
33
|
8M
|
CBT-65
|
Single coil
|
|
500mm
|
41
|
10M
|
CBT-65
|
Single coil
|
|
700mm
|
41
|
10M
|
CBT-65
|
Single coil
|
|
960mm
|
53
|
13M
|
CBT-65
|
Single coil
|
|
500mm
|
102
|
16M
|
BTO-10.15.22
|
Cross type
|
|
600mm
|
86
|
14M
|
BTO-10.15.22
|
Cross type
|
|
700mm
|
72
|
12M
|
BTO-10.15.22
|
Cross type
|
|
800mm
|
64
|
10M
|
BTO-10.15.22
|
Cross type
|
|
960mm
|
52
|
9M
|
BTO-10.15.22
|
Cross type
|
Feature
