Security Galvanized Steel razor barbed wire fence , razor sharp wire ISO
Security Galvanized Steel Razor Barbed Wire Fence , Razor Sharp Wire
razor barbed wire is a kind of blocking material, which is composed of blades made of galvanized steel or stainless steel plate with punching a sharp knife flake and a high tension galvanized core wire or stainless steel core wire. with its unique appearence and security, razor barbed wire can achieve excellent protection and screen effect. the mainly material of razor barbed wire are galvanized steel and stainless steel plate.
|
Reference
Number |
Thickness
|
Wire Dia
|
Barb
Length |
Barb
Width |
Barb
spacing |
|
BTO-10
|
0.5±0.05
|
2.5±0.1
|
10±1
|
13±1
|
25±1
|
|
BTO-12
|
0.5±0.05
|
2.5±0.1
|
12±1
|
15±1
|
25±1
|
|
BTO-18
|
0.5±0.05
|
2.5±0.1
|
18±1
|
15±1
|
35±1
|
|
BTO-22
|
0.5±0.05
|
2.5±0.1
|
22±1
|
15±1
|
36±1
|
|
BTO-28
|
0.5±0.05
|
2.5
|
28
|
15
|
46±1
|
|
BTO-30
|
0.5±0.05
|
2.5
|
30
|
18
|
46±1
|
|
CBT-65
|
0.6±0.05
|
2.5±0.1
|
65±2
|
21±1
|
101±2
|
1. Materials:galvanized iron wire,PVC coated wire ,stainless steel wire and stainless steel sheet
2. Blade Type:BTO-12 BTO-18 BTO-22 CBT-60 CBT-65
3. Wire Dia.:2.0-2.5mm
4. Bard Length:10-65mm
5. Barb Spacing:26-100mm
6. Classification:straight line razor wire,concertina wire,crossed razor barbed wire,razor wire mesh
7. Process and Features:Galvanized steel plate or stainless steel plate punched into certain forms then attached to the steel wire in sharp angle to form the blades.The products offer beautiful
appearance,economic cost,good frightening result and easy installation.Sharp blades coming in the form of concertina by buckles bring very good result of frightening and stopping to the aggressive
perimeter intruders .
8. Applications:widely used in military field,prisons,detention houses,government buildings and other national security facilities.Also fencing of residences,villa wall and windows,express way,railway,
national border lines,ets.
|
Outside Diameter
|
No. of Loops
|
Standard Length per Coil
|
Type
|
Notes
|
|
450mm
|
33
|
8M
|
CBT-65
|
Single coil
|
|
500mm
|
41
|
10M
|
CBT-65
|
Single coil
|
|
700mm
|
41
|
10M
|
CBT-65
|
Single coil
|
|
960mm
|
53
|
13M
|
CBT-65
|
Single coil
|
|
500mm
|
102
|
16M
|
BTO-10.15.22
|
Cross type
|
|
600mm
|
86
|
14M
|
BTO-10.15.22
|
Cross type
|
|
700mm
|
72
|
12M
|
BTO-10.15.22
|
Cross type
|
|
800mm
|
64
|
10M
|
BTO-10.15.22
|
Cross type
|
|
960mm
|
52
|
9M
|
BTO-10.15.22
|
Cross type
|
