Mobile Security Razor Fence Barrier Razor Wire Rapid Deployment Barrier
Mobile Security Razor Fence Barrier Razor Wire Rapid Deployment Barrier Dimension / size
1. Diameter of coil: 900mm
2. The length of the barricade minimum: 120 meters (3 x @ 40 m)
3. The width of the barricade: 1.8-1.9m
4. High barricades: 1.8-1.9m
5. The number of spirals: 55 of each coil (each 10 meters)
6. Razor wire: BTO-22
7. Zinc Coated :270 g /m² or as your request
Mobile Security Razor Fence Barrier Razor Wire Rapid Deployment Barrier Physical measurements
| Iterms | Properties | Request Limits |
| 1 | Blade Thickness(mm) | 0.5±0.05 |
| 2 | Core wire diameter(mm) | 2.5±0.1 |
| 3 | Barb Length(mm) | 22±1 |
| 4 | Barb Width(mm) | 15±1 |
| 5 | Barb Spacing(mm) | 35±1 |
| 6 | Wire Material | Hot dipped galvanized |
| 7 | Sheet Material |
Hot dipped gavalznied |
| 8 | Coil Diameter(mm) | 900mm*3 |
| 9 | Weight/Coil(KG) | 120KGS |
1.Use a long time;
2.Easy installation;
3.Strong Protection;
4.Economical and practical
Mobile Security Razor Fence Barrier Razor Wire Rapid Deployment Barrier Applications
1.It can be installed in the form of barbed tape wire or concertina coil to walls or fencing.
2.It is widely used to manufacture the wire fence for a fencing system or security system.
3.It is applicable in military field,airports fencing,prisons protection,detension houses, government buildings and other national security facilities.
