Coil Razor Barbed Wire Mesh Fencing Razor Barbed Tape Wire For Wall Top And Border
Razor barbed wire mesh fencing razor barbed tape wire used on wall top and border
Concertina
12″, 14″, 15″, 16″, 18″, 24″, 30″
We produce the above (depending on the size of the coil) in options of 3, 5, 7 or 9 clips.
Options of 31, 33, 51 and 56 spirals are available or alternatively, any spiral number the client requires to create a unique product to the buyer’s need.
Again, these sizes and spiral options are available in either stainless steel strip over stainless steel core wire (see steel specification attached). Stainless steel strip over galvanised core wire of the least cost option of galvanised strip over galvanised core wire.
Double Concertina
30″/24″
Standard 31 loop reinforced stainless steel of galvanised steel cold clinched around galvanised steel or stainless steel reinforcing wire (see specification attached).
Each cluster of barbs to be four needle sharp barbs on 4″ centres, each barb to measure 2,4″ in length.
Adjacent coil loops shall be alternatively clipped together and attached at 3 points of approximate equal spacing around the coil diameter. Length 20′ per roll.
| Razor Wire Concertina Specification / Options | |||||||
| Coil diameter | 300mm (12 in) |
450mm (18 in) |
730mm (28 in) |
730mm (28 in) |
980mm (36 in) |
980 mm (36 in) |
1250mm (50 in) |
| Recommended stretch length | 4 m | 10 m | 10 – 12 m | 15 -20 m | 10-15 m | 8 m | 8 m |
| Coil diameter when stretched | 400mm | 620mm | 600mm | 820mm | 850mm | 1150mm | |
| Spiral turns per coil | 33 | 54/55 | 54/55 | 54/55 | 54/55 | 54/55 | 54/55 |
| Clips per spiral | 3 | 3 | 5 | 3 | 5 | 7 | 9 |
