CBT65 CBT60 BTO22 Welded Razor Wire Mesh 75 * 150mm Diamond Hole
CBT65 CBT60 BTO22 75 * 150mm Diamond Hole Welded Razor Wire Fence
Welded razor wire fence is a multi-functional and high security fence. And is a new form of razor barbed wire. This fence is made of straight blade netting welded together, and it is very practical and looks beautiful. This kind of razor fence is almost impossible to climb or cut off with the general tools, also it has a neat appearance.
There are standard specifications of welded razor wire fence.
- Razor type: CBT-65, CBT-60, BTO-10, BTO-12, BTO-22, BTO-30.
- Coil diameter: 400 mm - 1000 mm.
- Raw material: High quality stainless steel wire and sheet, and high quality low carbon steel wire and sheet.
- Characteristics: BTO (Barbed Tape Obstacle), CBT (Concertina Barbed Tape).
- Coil Diameter: 400 mm, 450 mm, 500 mm, 600 mm, 700 mm, 800 mm, 900 mm, 950 mm, 1000 mm.
- Core wire: 2.5 mm.
- Sheet thickness: 0.5 mm.
- Custom specifications are available at your specific requirement.
Applications: Welded razor wire fence can be used as guarding fence, for doors and windows, and also be used in military. This product can protect you and your property, and ensures the safety of the protective barriers.
| Name | Welded Razor Mesh Specification | |||
|---|---|---|---|---|
| Welded Razor Mesh | Core Wire | Razor Strip (sheet) | Square Razor Mesh Size | Diamond Razor Mesh Size |
| 2.50±0.05 mm High Tensile Galvanised Wire Or stainless steel wire AISI304, AISI430, AISI316, AISI304L, AISI316L |
0.50±0.05 mm Galvanised sheet strip razor Or stainless steel sheet trip AISI304, AISI430, AISI316, AISI304L, AISI316L |
50 × 150 mm 75 × 150 mm 100x150 mm |
75 × 150 mm 150 × 300 mm |
|
| Other Mesh Sizes According to Customers' requirement | ||||
