Galvanized Or PVC Coated Blade Razor Barbed Wire , Concertina Barbed Wire
Blade Barbed Wire Razor Blade Wire Concertina Barbed Wire
Blade barbed wire aliases: blade barbed wire, blade barbed ring, blade barbed wire, etc., are formed by punching and cutting sharp blade strips of steel plates of different materials and wrapping them on the edges of steel wire cores of different materials. Zinc, or 304 stainless steel, can also be sprayed on the original material.
Blade barbed wire specifications: BTO-10, BTO-15, BTO-18, BTO-22, BTO-28, BTO-30, CBT-60, CBT-65, the most commonly used specifications in China are BTO-22, that is, blade length 22mm, blade width: 15mm, blade spacing 34mm, core wire diameter 2.5mm.
|
Blade specification |
Blade thickness |
Cor. Wire diameter |
Blade length |
Blade width |
Blade space |
| BTO-10 | 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 26±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.5±0.05 | 2.5 | 28 | 15 | 45±1 |
| BTO-30 | 0.5±0.05 | 2.5 | 30 | 18 | 45±1 |
| CBT-60 | 0.6±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±2 |
| CBT-65 | 0.6±0.05 | 2.5±0.1 | 65±2 | 21±1 |
100±2 |
Blade barbed wire packaging: moisture-proof paper, woven bag strips, other packaging can be packed according to customer requirements.
Common installation methods of blade barbed wire:
1. Determine the spacing of the brackets according to the expected distance and the requirements of the drawings
2. After measuring the distance, punch holes in the wall according to the chassis of the bracket and fix the bracket with expansion bolts
