Loose Nylon Ties Automatic Cable Tie Installation Tool With Handheld Zip Tie Gun
Loose Nylon Ties Automatic Cable Tie Installation Tool With Handheld Zip Tie Gun
Automatic cable tie installation tool, used in wire harness, plastic connectors, pipes and Led light. It improves the speed and be suitable for assemly lines.
Product specifications
| Product Name | Automatic cable tie installation tool | Model | SWT25080H |
| Cable ties model | T25080 | Mix bingding dia. | Ø2.0mm |
| Cable ties size | W2.5 * L80mm | Max binding dia. for wire | Ø14mm |
| Heat resisting(cable ties) | -30℃ - +80℃ | Max binding dia. for tube | Ø13mm |
| Pneumatic pressure | 5kg/cm² | Power | 220V, 50/60Hz, Euro plug |
Features
1. Using loose cable ties T25080, nylon cable ties size W2.5 * L80mm.
2. There is a handheld cable tie gun. Once touch the trigger, it start to wrap, tighten and cut off cable ties in 0.7S.
3. If binding failure, auto detect and deal with by itself.
4. 5 binding forces to choose. Biger numbers, stronger force.
5. It can bundle wire harness diameters from 2mm to 14mm.
6. If add a support/fixture, handheld cable tie tool can be as a fixed cable tie gun.
7 . Waste materials can be collected into a box.
8 . Touch the screen, Chinese/English languages.
Package info
The whole machine will divided two parts to ship for avoiding the bump each other.
74 * 70 * 85cm/wooden case, the host machine;
64 * 55 * 92cm/wooden case, the vibration bowl
Application
Automatically install nylon cable ties.
Wire harness cable ties installation
Such as wiring from fans, ovens, air conditioners
