Yk-920 Lead-edge Feeding System Corrugated Flexo Printer Slotter Machine for Easy Operation

Price Negotiable

Price: Negotiation

MOQ: 1set for Corrugated Three Color Flexo Printing Slotting Machine

Delivery Time: 120 Days After Deposit

Brand: YIKE GROUP

Product Description

Yk-920 Lead-Edge Feeding System Corrugated Flexo Printer Slotter Machine For Easy Operation

※Main Technical Parameters

YK-920 LEAD EDGE FEEDER PRINTER SLOTTER MACHINE
Wall board thickness	50 mm
Max Machine Speed (pcs/min)	150
Economic Working Speed (pcs/min)	120
Max. Feeding Size (mm)	900×2000
Min. Feeding Size (mm)	350x600
Max. Printing Size (mm)	900X1800
Standard Plate Thickness (mm)	3.9
Max slotter depth (mm)	300
Print precision (mm)	±0.3
Slot precision (mm)	±1.0
Suitable Cardboard Thickness (mm)	2 - 11

Lead-edge Feeding System

Can measure the corrugated cardboard thickness, can adjustment feeding gap automatic
7.5KW high-pressure centrifugal fans, according to the cardboard
warping degree of the frequency control pressure, to ensure warp
cardboard or thin cardboard high-speed accurate transmission.
Left and right side baffle position electrically adjustable,
screw-driven. and can remember computer.
The front baffle adjust the position of the upper and lower intervals

※Printer Unit

►Printing Roller

1. With printing plate

2. High quality steel production, surface grinded, hard chromium-plated. Static balance adjustment, stable operation, suitable for high speed running

3. Roller horizontal direction and circumferential direction with datum line, convenient for align plate

4. Fixed coil axis, suitable for standard hanging slats, realize rapid change plate

5. Electric 360° adjust printing roller, automatic digital display adjustment, remember store digital.

6. Installed with foot switch to control plate roller reversing, convenient change plate.

►Pressing Roller

1. Adopt high quality seamless delicately processing, dynamic balance adjustment, stable operation

2. Surface grinded, hard chromium-plated

3.Gear adopt backlash adjustment mechanism, adjustment none-affect gear enunciation, guarantee transmission accuracy

4. Printing roller can be adjusted for a distance 0-12mm

►Rubber Roller

1.Rubber roller adopts Guangdong Jingyang.

2.Overrunning clutch and automatic idling device, to prevent the ink dried

3. Rubber roller drum type middle part higher, to ensure ink quality

4. Rapid spaced spinner self-locking device, ensures uniform ink

5. Ink distributing roller independent drive mechanism, ensure ink quality

※Slotting Unit

Computer auto-control cardboard size by Linear guideway
6 shaft with rubber pre-creasing, creasing, slotter
The first pressure line round, after preloading cardboard not easily crush
The above press round Urethane appearance package, will not damage the cardboard
The slotter knife stock use a traverse mechanism, screw with linear guide, to move more flexible and precise
