RJ10 OEM Stainless Steel Universal 19mm Piezoresistive Silicon Pressure Sensor for Water Air Liquid Gas
RJ10 OEM Stainless Steel Universal 19mm Piezoresistive Silicon Pressure Sensor for Water Air Liquid Gas
|
material
stainless steel
Pressure range
-100kPa...0~10kPa...100Mpa
Pressure reference
Gauge | Absolute | Sealed
Supply
1.5mA
Temp. drift
≤±1.5%FS(@-20℃~85℃)
Ambient temp
-40℃~125℃
Protection
IP65
Material
Stainless steel 316
Certification
CE,ISo90001,RoHS
Response time
≤1ms (up to 90%FS)
Measured medium
All the liquids and gases compatible with 316L
|
■ With constant current and constant voltage excitation options
■ Imported highly reliable pressure die
■ Wide temperature compensation
■ Normalized output available
■ Compensation board filled with glue for protection against moisture
■ Φ19mm standard OEM
■ All 316L material
■ High performance, all solid, high reliability
■ 18 months warranty period
Applications
■ Process control systems
■ Pressure calibration instruments
■ Refrigeration equipment and HVAC control
■ Hydraulic systems and valves
■ Level measurement
■ Biomedical instruments
■ Ships and navigation
■ Aircraft and avionics systems
■ Weaponry
The company can also undertake special customization based on the needs of users, such as pressure sensors of all welded structure, wide temperature compensation, high reliability, anti-shock and anti-vibration sensors, especially for national defense weapons and equipment.
Service standards: we are committed to provide a high quality and responsive service to all clients
The fastest reply: Please feel free to contact us if you have any questions. You will get a reply from the professional and experienced trade manager within 24 hours. If our trade manager is off line, please leave a message, and tell us the product model you need and your E-mail address.
Quality assurance: good quality is assured by advanced manufacturing technology. And all products are through strict test by our professional QC team before shipping.
Door to door service: We usually send the parcel by DHL, EMS and TNT etc. The tracking number will be sent to you after delivery. It usually takes 3--5 working days to reach from from our side to your side, which is very convenient for your business
OEM available
1. What detailed information do I need to provide if I want to place an order?
We need to know the following information: Capacity, Usage and other related parameters you need.
2. Do you have any discount?
Yes, if you buy large QTY, please send us a email, we will give you a big discount.
3. What terms of payment are available?
We accept T/T, L/C, Trade assurance, Secure payment, Western Union, Paypal, Money Gram, etc.
4.When will you arrange the production?
We will arrange the production immediately after receiving your payment.
5. How do you ensure good product quality?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments before shipping to our clients.
