Stainless Steel Enclosure Waterproof China Weighing Indicator with Green Bright LED
Stainless Steel Enclosure High Precision Weighing Scale Indicator
ID511L is an electronic weighing indicator for different industrial environment. This unit can be widely used in Platform scale,Counting scale,Over/Under/Ok Classify Scale,Animal weighing scale......
Features:
* A304 stainless steel material
* 200,000 display division
* Two display range / two increment size
* RS232/485 (standard)
* 1″ display, green LED
* MODBUS_RTU
* Basic Functionality: ZERO,TARE,CLEAR and PRINT.
* Auto Tare, Auto Clear and Auto Print
* Print and Totalization
* X10/Over/Under/OK/Count/Animal Weighing/Unit Switch.
* Auto save battery and battery indicating
* Auto Power OFF
* Over/Under/OK alarm output with relay output
* External Input to Zero, Tare, Clear or Print.
* Power Input:100~264VAC, ≤ 0.1A
NI-MH battery gru, GP 7.2 VDC 3800mAh
Options:
* 1 Inputs /3 Outputs(Relay)
* RTC(Real Timing Clock)
Specifications:
| Accuracy | |
| Accuracy Class | III |
| EU Approval | 200,000 Display Division |
| Display Range | Two display range / Two increment size |
| Display & Keypad | |
| Display | 6 bits 1” high green LED display and 12 status lights |
| Update Speed | 100ms |
| Status Display | KG/LB, Center of Zero, Net/Gross, Motion, Battery |
| Key | 5 function keys(Tare, Clear,Zero,Function key,Print) |
| Power On/Off | Support |
| ADC | |
| Type | 24-bit |
| Speed | 100 Hz |
| Resolution | 0.05uV/d |
| Resolution Approved | 1uV/vsi(legal for trade) |
| Input | 0.1mV to 19Mv |
| Accuracy | 200,000d |
| Linearity and Stability | |
| In-linearity & TC | ≤0.0015% FS；≤5ppm/℃ |
| Load Cell | |
| Exciting Voltage | 5V DC, max 150mA |
| Load Cell Number | Max 4 x 350Ω |
| Connect Type | 4- wired or 6-wired , Cable:274mR/m2 |
| Scale Basic Functionality | |
| Calibration | 2-point or 3- point |
| Filter | 3-step |
| Scale Process | Auto Print and Print Totalization |
| Inputs | Option 1 Inputs for Zero, Tare, Clear or Print |
| Outputs | Option 3 Relay Output for Under/Ok/Over Alarm |
| Application | |
| Basic Weighting | Tare ,Zero ,Print, Auto Tare, Auto Clear and Auto Print, Unit switch |
| Classify | Over/Under/OK alarm output with relay output |
| Counting | Supported |
| Print and Totalization | Supported |
| Animal Weighing | Supported |
| Communication I/F | ||
| Serial Port | COM1-RS232/485 | |
| Continuous Output | Supported | |
| MODBUS-RTU | Report Weight, Remote Zero, Tare, Clear | |
| Housing | ||
| Harsh | IP66, Round housing bracket or Wall housing bracket | |
| Working Condition | ||
| Temperature | -10℃~40℃ ,95％ RH | |
| Power Supply | 110VAC ~ 220VAC,12W | |
Outline size:
