C3 Accuracy Weighing Scale Platform 1000kg-10000kg PF Series For Industrial
PF Series Capacity 1000kg~10000kg Carbon Steel Floor Scale Platform
Features:
* Carbon-steel construction, Powder-coated surface, anti-skidding design.
* Hermetically sealed steel weighing cell.
* Comprehensive product line with various weight ranges and platform sizes.
* Rugged structure guarantees high precision and reliability in logistics or warehouse applications.
* Four adjustable feet are very suitable for using on the floor.
Specifications:
| Model | Dimensions(mm) | Weight Range | ||||
| 1000kg | 2000kg | 3000kg | 5000kg | 10000kg | ||
| PF1010 | 1000*1000 | * | * | * | ||
| PF1212 | 1200*1200 | * | * | * | ||
| PF1215 | 1200*1500 | * | * | * | ||
| PF1515 | 1500*1500 | * | * | * | * | |
| PF1520 | 1500*2000 | * | * | * | * | |
| PF2020 | 2000*2000 | * | * | * | * | * |
| Verification division value | 0.5kg | 1kg | 1kg | 2kg | 5kg | |
| Accuracy level | C3 | |||||
| Working temperature | platform and load cell:-35℃~+65℃ | |||||
| Relative humidity | ≤95%(need no condensation) | |||||
| IP | load cell IP65 | |||||
| Load cell | ZEMIC H8C | |||||
| Model | L | W | H | H1 | ΦD |
| PF1010 | 1000 | 1000 | 115 | 70 | 60 |
| PF1212 | 1200 | 1200 | 115 | 70 | 60 |
| PF1215 | 1500 | 1200 | 115 | 70 | 60 |
| PF1515 | 1500 | 1500 | 115 | 70 | 60 |
| PF1520 | 2000 | 1500 | 130 | 80 | 60 |
| PF2020 | 2000 | 2000 | 130 | 80 | 60 |
Optional accessories:
| * Ramp
Stainless steel: for wet environments Hot galvanized: for dry environments |
|
| * Scale stand
Stainless steel: for fastening the terminal on the weighing platform |
|
| * Roller table
Stainless steel: for wet environments Hot galvanized: for dry environments |
|
| Integrated wheels are easy to operate |
