Weighing Indicator Controller With Replay Output , 4 / 6 Output Target Control Indicator
Price:
negotiation
MOQ:
Negotiable
Delivery Time:
5~25 days
Product Description
Weighing Control Indicator with 4 Input and Relay 6 Output
Target Control Application:
| OVER/UNDER/OK | Support |
| Zero Tolerance | Support |
| Target Control | Simple Setpoint or Sequence Control(with Start & Abort command) |
| Bagging PAC | 3-Speed Control, bag clamping control and empty control |
| Filling PAC | No-Gun-Control Filling / Gun-Control Filling |
Brief Discriptions:
ID550 is a high precision weighing display controller. This weighing control indicator can support simple weighing,MODBUS-RTU,4-20mA output,batching and target process control.
Indicator Features:
* 5-step filter, high accuracy, high anti-vibration
* 200Hz A/D sample speed, 200 Hz target compare speed
* One standard serial port: RS232/485
* 6-bit 0.56” LED display and 5 status lights
* Standard: Report Weight MODBUS_RTU
* No-Testing Calibration(CalFree)
* 4 Inputs /6 Outputs (Relay)
Indicator Parameters:
| Accuracy | |
| Accuracy Class | III |
| EU Approval | 100,000 Display Division, CMC 6000e |
| Display/Keypad | |
| Display | Green LED display, 0.56” high(14.2mm) |
| Update Speed | 250ms |
| Status Display | Gross, Net, Motion, Center of Zero, Kg/Lb |
| 4 Function Keys | Tare, Clear, Zero, Print |
| ADC | |
| Type | 24-bit |
| Speed | 200 Hz |
| Resolution | 0.06uV/d |
| Resolution Approved | 1uV/vsi(legal for trade) |
| Input | 0.1mV to 19Mv |
| Accuracy | 100,000d |
| Load Cell | |
| Exciting Voltage | 5V DC, max 150mA |
| Load Cell Number | Max 6 x 350Ω |
| Connect Type | 4- wired or 6-wired, Cable:274mR/m2 |
| Scale Functionality | |
| Calibration | 2-point with testing weight or no testing(CalFree) |
| Filter | 5-step |
| Scale Process | Tare, Zero, Auto Zero, Motion |
| Inputs | 4 Inputs, Can be assigned remote inputs for remote host(PLC or DCS) |
| Outputs | 6 Outputs, Can be assigned remote outputs for remote host(PLC or DCS) |
| Communication I/F | ||
| Serial Port | 1 port: RS232/485 | |
| Continuous Output | 10ms ~ 20ms (100~50 Hz) | |
| MODBUS-RTU | Support, Integer & Floating data format | |
| Housing | ||
| Panel Mount | IP65 | |
| Working Condition | ||
| Temperature | -10℃~40℃, 95％ RH | |
| Power Supply | 24VDC, 6W | |
Product Pictures:
