Renewable Energy System Bifacial Solar Panels 182mm 144pcs Monocrystalline Solar Cells
Price:
Negotiable
MOQ:
840PCS/HQ
Delivery Time:
15 working days after order onfirmation
Brand:
Rixin
Product Description
Renewable Energy System Bifacial Solar Panels 182mm 144pcs Monocrystalline Solar Cells
Mono DDP315-325(K)
| Model | DDP315(K) | DDP320(K) | DDP325(K) |
| Maximum power(Pm/Wp) | 315 | 320 | 325 |
| Maximum power voltage(Vmp/V) | 29.3 | 29.4 | 29.5 |
| Maximum power current(lmp/V) | 10.75 | 10.88 | 11.00 |
| Open circuit voltage(Voc/V) | 35.9 | 36 | 36.1 |
| Short circuit current(Isc/A) | 11.54 | 11.60 | 11.66 |
| Module efficient(%) | 19.0 | 19.3 | 19.6 |
Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5
Mechanical performance parameters
| Cell Nos & array | Mono half-cut cells 108 (6*9*2) |
| Appearance color | Black |
| Cable | 4m㎡ negetive1000mm,positive1000mm |
| Module weight (kg) | 19 |
| Module dimension (L*W*H)(mm) | 1600*1036*5mm |
| Packing | 33pcs/pallet |
| Power optimizer matching form | 2 modules equipped with 1 optimizer |
Quality parameters
| Module working temperature range (℃) | -40~ +85 |
| Power tolerance(W) | 0~+5 |
| Maximum system voltage(V) | DC1500 |
| System maximum protection current(A) | 20 |
| NOCT(℃) | 45±2 |
| Front/rear static loads(Pa) | 2400 /2400 |
| Junction box/Connector | Ip68,split / MC4 compatible |
Temperaturecoefficient(STC)
| Temperature coefficient of Voc | -0.3%/℃ |
| Temperature coefficient of Isc | +0.06%/℃ |
| Temperature coefficient of Pm | -0.39%/℃ |
| Test condition:irradiance=(1+0.1BiFi)1000W/㎡,ambient temperature=25℃,AM=1.5 | |
Quality warranty
12-year material & workmanship warranty
30-year linear power warranty
Datasheet of Renewable Energy System
| SPECIFICATION | |||||
| Description | Ground mounting | Roof bracket | Carport | Agricultural bracket | Single column stand |
| Field status | open area | ||||
| Max wind load | ≤60m/s | / | <46m/s | <46m/s | ≤46m/s |
| Height | Depending | ||||
| Snow load | Depending | ||||
| Tilt Angle | 0~45° | As per requirement | 0~45° | 0~30° | 0~45° |
| Mount Directions | Vertical,horizontal | ||||
| Standard | GB/T2518-2008 & GB/T10125-2012 | ||||
| Body material | S550GD+Z350 | ||||
| Bolt material | SUS304 | ||||
| Base material | Q235/Cement | ||||
| Surface treatment | Galvanized mg-al | ||||
| Warranty | 10 Years | ||||
Why it's worth to choose Rixin system for photovoltaic farms?
Up to 25 years' product warranty on anti-corrosion coating
High durability
Extremely high corrosion resistance
No electrocorrosion effect
Safety and standards confirmed by certificates
