Sandwich System Synthetic Permeable Tartan Athletics Track
Sandwich System Tartan Athletics Track , Synthetic Permeable Tartan Running Track
Yuanyang running track systems are designed for application over properly prepared asphalt, concrete or latex-based running track surfaces. Yuanyang Sports systems contain small rubber granules that enhance the flexibility of the coating and add to the overall shock absorption of the surface. Our synthetic running track formulations beautify and protect against oxidation, raveling, and moisture penetration.
Yuanyang Sports is available in all standard colors by utilizing ColorPlus Pigment Dispersion. ColorPlus contains high quality pigments to ensure vibrant color, hiding, and many years of non-fading performance.
TrackMaster Plus uses include:
- Resurfacing existing SBR latex running tracks.
- Use as an athletic track surface on new or existing surface (asphalt or concrete).
- Walking path, jogging trails, middle and high school track
- Coating for rubberized asphalt track
- Military Running Tracks
13mm thickness all weather fully cast in site sandwich type polyurethane synthetic running track system equivalent to synthetic consist of 9mm thick resilient cushion layer of polyurethane (PU) Binder bonded with SBR granules by paving machine and red ethylene propylene diene monomer( EPDM) granules size 2-4mm sprayed to permanently embedded on top of SBR layer in accordance to IAAF requirement.
TECHNOLOGY INDEX
| Property | Requirement | Testing Data | Remark |
| Force Reduction,% | ≧20 | 23 | REFER TO SPECIFICATION INDEX GB/T14833-1993 |
| Compression Recovery Rate % | ≧95 | 97 | |
| Tensile Strength Mpa | ≧0.7 | 0.7 | |
| Elongation | ≧40 | 75 | |
| Fire Resistance | 1 | 1 |
From : China National Sport Goods Quality Supervision Inspection Center
TEST REPORT
| Test Item | Standard | Test Data | Judge | |
| Thickness mm | ≥13 | 15 | Standards | |
| Force Reduction | 0℃ | 35-50 | 35.9 | Standards |
| 20℃ | 37.3 | Standards | ||
| Vertical Deformation | 0℃ | 0.6-2.5 | 1.69 | Standards |
| 20℃ | 1.83 | Standards | ||
| Tensile Strength Mpa | ≥0.4 | 0.54 | Standards | |
| Elongation at Break % | ≥40 | 67 | Standards | |
| Skid Resistance BPN20℃ | ≥47 | 60 | Standards | |
| Conclusion | All test item cater to IAAF certification requirement | |||
From : Sports Surface Testing Laboratory of Chinese Athletic Association
Application :
Standard athletic running track competition playground , school playground, jogging track, safety rubber playground ,stadium tartan track, trace and field surface ,etc.
Case
About Company
Yuanyang Sports established in 2006, focus on sports flooring solution materials researching and developing, lead in the China market in past 11 years ,and located in Zhongshan city ,Guangdong province covered 10000 sqm workshop with more than 50 tons output per day. The products are synthetic running track , sports court flooring , EPDM /TPE granules and artificial grass, etc. It almost contacts all solution for sports flooring.
Our Team
Production Line
Package
If you are interested in getting cost estimates for running track construction or resurfacing, contact us for referrals to qualified sport surfacing contractors in your area.
