Steady Performance High Pressure Mud Pump Good Intensity With High Capacity
Mud pump station for HDD machine, Pipelaying project 1500L
CWB-1500
(Mud pump main parts material)
|
(Part name) |
(Choose the material of) |
(Prominent feature ) |
|
The pump head |
35# Steel |
After forging compression performance is superior |
|
Valve seat |
40Cr |
After forging impact resistance will be stronger |
|
Sealing ring |
Polyurethane |
Excellent wear resistance |
|
Cylinder liner |
Cast ceramic |
High hardness, excellent wear resistance |
|
Guide the slider |
QT600-3 |
Excellent wear resistance |
|
Piston rod |
3Gr13 |
Excellent corrosion resistance Polishing performance! High strength and wear resistance |
|
piston |
NBR rubber |
Excellent wear resistance |
|
Piston rod fastening nut |
ZQAL9-4 |
Not rust, easy dis assembly |
|
Connecting rod bearing |
SF-1 |
Excellent wear resistance |
|
Guide sleeve |
GCr15 |
High hardness, excellent wear resistance |
|
Crankshaft |
40Cr |
After forging impact resistance will be stronger |
