12V 2000A 24KW IGBT Electroplating Rectifier High-Power For Nickel / Copper / Silver / Gold Plating Industrial-Grade Durability

Product Description

Product Parameters

Input Specifications

• Voltage: 3-Phase AC 440V
• Frequency: 50/60Hz

Output Specifications

• Voltage Range: 0-12V continuously adjustable (digital display, adjustment accuracy ≤1%)
• Current Range: 0-2000A continuous output (constant current/constant voltage dual-mode switching)
• Output Ripple: ≤1% (high-frequency PWM modulation technology)
• Efficiency: ≥89% (IGBT topology with nanocrystalline transformer)

Protection Functions

• Overcurrent Protection
• Overheat Protection
• Overvoltage/Undervoltage Protection
• Short Circuit Protection

Certifications and Compliance

• Safety Certifications: CE certified (compliant with LVD, EMC, and RoHS directives)
• Industry Standards: Meets IEC 60950-1 (Safety of Information Technology Equipment) and ISO 9001 quality management system

Typical Application Scenarios

• Metal Plating: Single-metal and alloy coatings (nickel, copper, silver, gold) for electronic components, jewelry, and automotive parts.
• Surface Treatment: Anodizing, electropolishing, electroforming, and other processes requiring high current density.
• Industrial Production: Large-scale plating lines requiring long-term stable power supply, such as PCB manufacturing and bathroom hardware processing.
