SKY2000-N₂ Handheld Pumped Nitrogen Gas Monitor 0-100%VOL for Food Packaging & Inert Gas Purity Check
Overview
The SKY2000-N₂ is a portable, pump-driven gas detector specifically designed for accurate measurement of nitrogen (N₂) concentration in the range of 0–100%VOL. Based on the proven SKY2000 series platform, this device integrates an electrochemical nitrogen sensor, offering fast response, high reliability, and excellent portability. It is particularly suitable for food packaging lines, modified atmosphere packaging (MAP), nitrogen flushing processes, and inert gas purity verification.
Product Pictures
Key Advantages
- Accurate Nitrogen Measurement – Electrochemical N₂ sensor with 0–100%VOL range and 0.1%VOL resolution ensures precise monitoring of nitrogen content in packaging environments.
- Built-in Sampling Pump – Integrated pump enables rapid gas extraction from sealed food bags, packaging headspace, or confined production areas.
- Robust & Safe Design – Explosion-proof certified (Ex ia IIC T4 Ga) with IP66 protection rating. High-strength engineering plastic housing resists industrial conditions.
- User-Friendly Operation – LCD dot matrix display with backlight supports Chinese/English interface. One-key restoration to factory settings, plus zero and span calibration functions.
- Data Logging (Optional) – Stores up to 100,000 readings; data can be exported via USB to PC for quality control traceability.
Technical Specifications (for N₂)
| Parameter | Value |
|---|---|
| Gas Detected | Nitrogen (N₂) |
| Detection Principle | Electrochemical |
| Measurement Range | 0 – 100%VOL |
| Resolution | 0.1%VOL |
| Precision | ≤ ±1–5% F.S. (typical for electrochemical gases) |
| Response Time | ≤ 20 seconds |
| Repeatability | ≤ ±1% |
| Zero Shift | ≤ ±1% F.S./year |
| Recovery Time | ≤ 10 seconds |
| Linearity Error | ≤ ±1% |
| Operating Temperature | -20℃ – +50℃ |
| Operating Humidity | 0–95% RH (non-condensing) |
| Alarm Mode | Sound, light, vibration |
| Display | LCD dot matrix with backlight |
| Pump Operating Time | 100 hours (pump off) |
| Degree of Protection | IP66 |
| Explosion-Proof Grade | Ex ia IIC T4 Ga |
| Dimensions | 205 × 75 × 32 mm |
| Weight | 300 g |
Key Applications – Food Packaging Focus
- Nitrogen flushing line monitoring – Ensure proper oxygen displacement in food bags (e.g., snacks, coffee, nuts).
- Modified Atmosphere Packaging (MAP) – Verify nitrogen concentration before sealing to extend shelf life.
- Cold storage / Controlled atmosphere – Complement to ethylene detection for freshness preservation.
- Industrial inerting – Check nitrogen purity in tanks, pipelines, or confined spaces.
Why Choose SKY2000-N₂ for Food Packaging?
- Fast pump sampling allows direct measurement from inside a sealed package via a sampling needle or tube.
- High resolution (0.1%VOL) detects small deviations in nitrogen purity, preventing oxidation spoilage.
- Compact, lightweight (300g) – easy to carry between packaging lines or quality control labs.
