I-SUZU 700P 4x4 RHD 190hp Garbage Compactor Truck and 9m³ Compaction Volume
Price:
20000
MOQ:
1
Delivery Time:
30DAYS
Brand:
CLW GROUP
Product Description
I-SUZU 700P 4x4 RHD Compactor Garbage Truck 190HP
This I-suzu 700P 4x4 right-hand drive compactor garbage truck is purpose-built for reliable waste collection and compaction in urban, suburban, and rugged environments. Powered by a 190HP I-suzu diesel engine, it delivers robust performance paired with professional compaction capabilities to maximize operational efficiency.
Technical Specifications
| Chassis Specifications | ||
|---|---|---|
| Product Name | I-SUZU 4x4 Compactor Garbage Truck (9m³) | |
| Cab | Single row cabin, Right Hand Drive (RHD), with A/C | |
| Wheelbase | 3815 mm | |
| Engine Model | 4HK1-TCG61 | |
| Horsepower | 190 HP | |
| Emission Standard | Euro VI | |
| Gearbox | 6 forward speeds + 1 reverse | |
| Gross Vehicle Weight | 11000 kg | |
| Front/Rear Axle Loading | 4000 kg / 7000 kg, with ABS | |
| Tires | 235/75R17.5 16PR, 6 units + 1 spare | |
| Drive Type | 4x4 | |
| Superstructure Specifications | ||
| Compaction Volume | 9 m³ | |
| Compaction Mechanism | Hydraulic scraper + sliding plate system | |
| Control Mode | Wired + wireless remote control | |
| Core Functions | Single cycle / Continuous cycle / Reverse cycle | |
| Body Material | High-strength wear-resistant steel | |
| Tailgate Operation | Hydraulic lifting and lowering, fully sealed | |
| Waste Compaction | High compression ratio to maximize loading capacity | |
| Operation Safety | Emergency stop button, overload protection | |
Product Gallery
Key Features
- Chassis & Powertrain: Built on the durable I-suzu 700P 4x4 chassis with a 190HP diesel engine, offering excellent traction and power for both on-road and off-road waste collection tasks. The right-hand drive configuration ensures compliance with regional traffic regulations.
- Compaction System: Equipped with a high-efficiency hydraulic compaction mechanism (max compression pressure up to 6 tons) that increases waste density, doubling the effective loading capacity compared to standard garbage trucks. Supports single-cycle, continuous-cycle, and reverse-cycle operations via wired and wireless remote control.
- Operation Flexibility: Dual control modes (cab-integrated panel + wireless remote control) enable safe, one-person operation. The system supports functions including tailgate lifting/lowering, scraper opening/closing, and sliding plate up/down movements for versatile workflow management.
- Durable Construction: The compactor body is made of high-strength steel with reinforced wear-resistant plates, designed to withstand continuous compression cycles and corrosive waste materials. The sealed body prevents leaks and odors during transport.
- User-Friendly Cab: Ergonomically designed driver's cabin with comfortable seating, clear controls, and good visibility, ensuring long-shift comfort for operators.
Applications
Ideal for municipal waste management, residential and commercial waste collection, and sanitation services in regions requiring right-hand drive vehicles. The 4x4 capability also makes it suitable for challenging terrains such as construction sites, rural areas, and mountainous regions.
