FAW JK6 6x4 Crane Truck 320HP 25T Payload Capacity With XCMG Folding Boom Crane
Price:
20000
MOQ:
1
Delivery Time:
30DAYS
Brand:
CLW GROUP
Product Description
FAW JK6 6x4 320HP 25T Folding Boom Crane Truck with Hydraulic Loading Ramp & Rear Outriggers
Product Overview
This FAW JK6 crane truck is a multi-functional heavy-duty workhorse designed for both lifting and hauling tasks. Built on a reliable FAW JK6 6x4 chassis powered by a 320hp engine, it features an 8-ton XCMG folding (knuckle boom) crane with 3 telescopic sections, a 16.8 t*m lifting moment, and a built-in hydraulic winch for enhanced pulling power.
Equipped with a dual-section hydraulic loading ramp at the rear, it allows easy loading and transport of heavy machinery like excavators, forklifts, and other equipment directly on the flatbed cargo body. The rear outriggers provide exceptional stability during lifting operations, while the foldable crane design ensures compact dimensions for road travel.
Technical Specifications
| Category | Parameter | Specification |
|---|---|---|
| Basic Info | Product Name | FAW JK6 6x4 Folding Boom Crane Truck with Hydraulic Ramp |
| Gross Vehicle Weight | 25,000 kg | |
| Payload Capacity | Up to 25 tons (for construction machinery/heavy loads) | |
| Chassis | Make & Model | FAW JK6 6x4 |
| Cab Type | One-and-a-half row cabin, LHD, with A/C | |
| Wheelbase | 5600 + 1350 mm | |
| Engine Model | CA6DL1-32E5 | |
| Horsepower | 320 HP | |
| Emission Standard | Euro 5 | |
| Gearbox | 9 forward + 1 reverse | |
| Front/Rear Axle Loading | 6700 kg / 13000 kg × 2, with ABS | |
| Tires | 12R22.5 16PR, 10 pcs + 1 spare | |
| Crane | Crane Make & Model | XCMG SQZ160 Folding Boom Crane |
| Max Lifting Moment | 16.8 t*m | |
| Crane Capacity | 8-ton class, 3-section folding boom | |
| Winch | Hydraulic winch with steel wire rope and hook | |
| Outriggers | Full set of stabilizers (front + rear) for lifting safety | |
| Body & Ramp | Cargo Body | Reinforced flatbed with diamond plate floor, side gates |
| Loading Ramp | Dual-section hydraulic foldable ramp for heavy machinery loading | |
| Ramp Capacity | Matched for 25-ton equipment loading |
Product Gallery
Key Features
✅ FAW JK6 Chassis: 6x4 drive, 320HP engine, durable and fuel-efficient for long-distance transport
✅ 8T Folding Boom Crane: 3-section articulated arm, max lifting moment 16.8 t*m, hydraulic winch included
✅ Hydraulic Loading Ramp: Dual-section foldable ramp for heavy machinery loading/transport
✅ Full Outriggers: Front and rear stabilizers for safe, stable lifting at full capacity
✅ Flatbed Cargo Body: Reinforced diamond plate floor for heavy loads, with side boards
✅ User-Friendly Controls: Side-mounted hydraulic levers for crane and ramp operation
Ideal Applications: Construction, equipment rental, mining, landscaping, and utility projects. This all-in-one truck eliminates the need for separate hauling and lifting vehicles, boosting your operational efficiency and cost-effectiveness.
