6-Ton All-Wheel Drive Refrigerated Truck with KCOLD Refrigeration Unit
Price:
20000
MOQ:
1
Delivery Time:
30DAYS
Brand:
CLW GROUP
Product Description
6Tons All-Wheel Drive Refrigerated Truck with Non-Independent Refrigeration Unit
This 4x4 6-ton all-wheel drive refrigerated truck is purpose-built to deliver reliable cold chain transportation in challenging terrains and remote locations. It combines robust off-road capability, efficient refrigeration performance, and durable construction, making it ideal for delivering temperature-sensitive goods such as food and vaccines in harsh environments.
Powered by a high-performance diesel engine and paired with a proven 4x4 all-wheel drive system, this truck delivers exceptional traction and stability on muddy, gravel, or unpaved roads. The heavy-duty chassis and rugged 8.25R16 tires ensure reliable performance even in the most demanding conditions, allowing you to reach remote areas inaccessible to standard two-wheel drive vehicles.
Technical Specifications
| Chassis Specifications | |
|---|---|
| Drive Type | 4×4 Full-time All Wheel Drive |
| Rated Payload | 6000kg (6 Ton) |
| Cab Type | Single row cab, 2/3 seats, air conditioning optional |
| Engine | Diesel engine, high torque, low fuel consumption, Euro 5 / Euro 6 emission standard |
| Transmission | Manual transmission, synchronized gear shifting, with transfer case |
| Off-road Configuration | High/low speed gear, differential lock, strong climbing ability, suitable for muddy, gravel, mountain and unpaved roads |
| Tire Specification | Off-road heavy-duty tires, anti-skid and wear-resistant |
| Braking System | Air brake system, ABS, stable and reliable braking performance |
| Structure | Heavy-duty reinforced frame, anti-corrosion treatment, strong load-bearing capacity and impact resistance |
| Ground Clearance | High ground clearance, excellent trafficability in complex terrain |
| Superstructure Specifications | |
| Cargo Box Material | High-strength glass fiber reinforced plastic (FRP) insulated panel, integral foam molding, food-grade material |
| Insulation Layer | High-density polyurethane foam, low thermal conductivity, excellent heat insulation effect |
| Temperature Range | -18℃ ~ +20℃ (adjustable according to cargo requirements) |
| Floor Structure | Aluminum checkered anti-slip floor, waterproof, corrosion-resistant, easy to clean |
| Box Door Configuration | Rear double door (side door optional), equipped with sealing rubber strip to prevent cold air leakage |
| Cold Air Curtain | Equipped with PVC cold air curtain, effectively reduce temperature loss during loading and unloading |
| Anti-corrosion Treatment | Integrated anti-aging and anti-corrosion process, suitable for long-term outdoor and harsh environment operation |
| Refrigeration Unit Specifications | |
| Type | Non-independent refrigeration unit (engine-driven) |
| Brand | KCOLD |
| Power Mode | Driven by vehicle engine, no external power supply required |
| Cooling Performance | Fast cooling speed, quick temperature recovery after door opening, stable constant temperature operation |
| Energy Consumption | Low fuel consumption, energy-saving and high efficiency |
| Working Environment | Adapt to high temperature, low temperature and complex outdoor working conditions |
| Control System | Intelligent digital temperature control, real-time temperature display, precise temperature adjustment |
| Advantages | Compact structure, easy installation, low failure rate, convenient maintenance |
Key Features
4x4 all-wheel drive system for superior off-road performance
6-ton payload capacity for efficient cold chain logistics
KCOLD non-independent refrigeration unit with reliable cooling performance
High-insulation cargo box with temperature control range -18°C ~ +20°C
Durable aluminum checkered floor and cold air curtains for optimal efficiency
Optional hydraulic tail lift (max 2000kg) for easy loading/unloading
Heavy-duty tires and rugged chassis for harsh terrain adaptability
Ergonomic cab design for driver comfort and safety
Applications
Ideal for remote area food distribution, pharmaceutical and vaccine transportation, disaster relief cold chain support, logistics, and other scenarios requiring reliable refrigerated delivery in challenging environments.
