Fuel Haulage Fuel Delivery Truck Oil Tank Semi Trailer With Vapor Recovery
48,000Liters 34Ton Oil Tank Semi-Trailer with Vapor Recovery for Large Bulk Fuel Haulage
Product Description
- 48,000liters Large Bulk Fuel Delivery Truck.
- Tank Material: Q235B
- Can choose Different Compartment with separate Discharging Valves & Hose
- Main Beam: Q345B high tension steel in I style
- Axles: FUWA, BPW, York, HJ, L1 Axles
- Suspension: Leaf Spring Suspension
- Tire: 11R22.5, 12R22.5 Tubless Tire.
- Optional Vapor Recovery System
Specifications of 48,000Liters 34Ton Oil Tank Semi-Trailer for Large Bulk Fuel Haulage
| 48m3 Fuel Tanker Trailer | |||
| Overall Size | 12990 x 2500 x 3900 mm | ||
| Overall Trailer Weight | 11,000 kg | ||
| Tanker | Tanker Shape | Elliptical Shape | |
| Material | 5mm Carbon Steel Q235B | ||
| Capacity | 48 Cubic Meters | ||
| Compartment | 4Piece, 8+16+16+8cbm | ||
| Manhole | 4 Sets, 500mm Manhole with Breather Valve, Overfill Sensor. | ||
| Bottom Valve | 4 Sets Bottom Valve for Emergency Cut-off | ||
| Discharging Filling Valve | 4 set ∮100mm discharging valves | ||
| Chassis | |||
| Frame | High Tension Frame Steel Q345B, in 8mm side frame & 10mm main frame | ||
| Axle | 3 Axles Fuwa 12T | ||
| Suspension | 1 Set Mechanical Leaf Spring Suspension | ||
| Brake | WABCO Air Brake | ||
| Kingpin | 1 Piece JOST, 2” or 3.5” Bolted | ||
| Landing Gear | 1 Unit JOST 28T | ||
| Tire | 12 Pieces with 1 Spare 12R22.5 Tubeless Tire, Aeolus Brand | ||
| Ground Wires | Anti-Static Ground Wires | ||
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | ||
| Extinguisher Holder | 2 Pieces | ||
| Tool Box | 1 Standard Tool Box | ||
Our Service
-
Quick feedback to solve your questions
-
Professional engineering and production team
-
Related Accessories and spare parts offered,no future worries
-
Regular customer after-sale visiting
-
Free technical staff training and guidance
-
Reasonable price and good quality
-
Quick delivery and shipment
FAQ
Q1: What kinds of fuel delivery truck I can order from your company?
A: There are various sizes of fuel delivery truck with different functions,you can contact us and tell your request.We will recommend you suitable product.
Q2:: Have you supplied fuel delivery truck to any overseas companies?
A: Yes,with need of cleaning cities,we offered fuel delivery truck to many Africa and south-east Asian countries.
Q3 What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
