45CBM Carbon Steel Q235 Jet A1 Tank Semi Trailer With Epoxy Coated Inside
Tri Axle 45000L 45CBM Oil Tanker Carbon Steel Jet A1 Transport Tank Semi Trailer With Epoxy Coated Inside
Description:
** Tank material could be carbon steel, stainless steel, alluminum...
** It can be divided into many compartments to load different types of fuels.
** BPW axles, JOST kingpin, JOST landing gears, Air suspension, ABS.
** Heat preservation of rock cotton or polyurethane foaming, Heating system.
** Bottom loading system can be equipped: API connections, over-fill detection system , vapor recovery vent, vapor recovery adaptors & dust cap, pneumatic control, bottom emergent valve...
** Tube or tubeless tyres, off-road single tyre for bad roads.
1. Purpose: It used for transporting all kinds of chemical liquid such as diesel and gasoline etc.
2. Main parts: Axle, Bottom valve, pipeline and liquid line.
3. Tank material for optional: Carbon steel, Stainless steel 304, Stainless steel 316, Stainless steel 316L and Aluminium alloyetc.
4. Available tank volume: 38CBM - 60CBM/2 Axles/3 Axles/4 Axles
5. Axle brand: China famous brand FUWA/China brand L1/Germany brand BPW.
product Specification
| Main Dimensions | ||
| Overall Length | Approx.11800mm | |
| Overall Width | 2500mm | |
| Overall Height | Approx.3650mm | |
| Tare Weight | Approximate 10500KGS | |
| Loading Capacity | 45m3 | |
| Tank Body | ||
| Shape | Mono block Cylinder | |
| Total Volume(m3) | 45CBM | |
| Tanker Body Material | 5mm Carbon Steel Q235 | |
| End plate | 6mm Carbon Steel Q235 | |
| Lifting Ladder | Including Top walkway and backside steel material | |
| Manhole cover | 4 sets Aluminum alloy API manhole cover , ∮500mm , with breather valves and anti-Spillage valves | |
| Bottom Valve | 4 sets, DN100 Pneumatic Bottom Valve, Pneumatic control for each compartment | |
| Discharging valve | 4 sets DN100 API discharging valves | |
| No.of Compartment | No. Of 4 | |
| Discharging Pipe | 4”rubber hose | |
| Chassis | ||
| Main Beams | Special design I beam, Steel Saddle support 8 No’s each side. | |
| Axle | 3 axles | |
| BPW brand 13 Ton | ||
| Landing Gear | JOST brand | |
| King Pin | JOST Brand 2’’ or 3.5” bolt-in king pin;interchangeable. | |
| Suspension | Full set of heavy duty leaf spring type | |
| Pneumatic Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks. | |
| Tire | 385/65R22.5 tubeless Single Tri-angle Brand tire with one spare tire, 7 pieces | |
| TOTAL standard Lighting system |
1. Electrical wires: Placed in leak tight sheathes,neither bare wire nor split sheathes 2. Back lights:Inserted inside rear bumpers and protected. 3. Stop light:Additional LED stop lighting. 4. Lighting repeaters:Turn,reverse and stop lights must be repeated on top left and right sides. 5. Indicator: In the rear side. |
|
| Other TOTAL Design and parts |
1. Dust Board to Cover the Tires 2. Rear Ladder to access the top of the tanker. Well secured,with angle,not vertical,linked to mechanism for automatic handrail lifting. 3. Walkway with fold-able handrail. (air operated)
|
|
Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.
Our service
Before purchasing:
- Quick reply on customers' inquiry;
- Professional suggestion on truck choice according to different countries.
- Details quotation with spec.and reasonable price.
- Welcome to visit our company before purchasing.
After purchasing:
- Production pictures and video updated every week.
- Customer can visit factory after truck completion or arrange third party inspection.
After-sales service:
1- English Operation Video
2- Free operation and technical train at factory but not include accommodation
3- Spare parts supplied at factory price whenever needed.
4- Engineers can be sent to your country and offer local engineering support and train.
