Q345R Carbon Steel 8,000 Liters LPG Gas Tanker For Storage Lpg
Price:
negotiable
MOQ:
1 Unit
Delivery Time:
20~30 days after receiving deposit
Brand:
CLW
Product Description
Q345R Carbon Steel 8,000 Liters LPG Gas Tanker for Storage lpg For Nigera
Product Description
1. Storage medium of propane Storage Tank :
- LPG, Liquid ammoina,Dimethyl ether,Iso-butane,Pentane and etc.
2. Available tank capacity of propane Storage Tank:
- 5m³~200m³,2ton~100tons
3. Manufacturing standards of propane Storage Tank :
- GB-150, ASME VIII Division I U STAMP, CCC, ISO9001 : 2008
4. Optional for lpg gas plant equipments
- lpg pump and motor,lpg compressor,volume flow meter,filling scales and lpg dispenser,ball valves,check valves,non-return valves,glass valve,strainer,by-pass valve.
6.Maintenance-free operation with simple calibration and proof testing.
7.20 years guarantee against manufacturing defects.
| 40,000Liters LPG Storage Tank Dimension | |||
| Volume of Tank | 8,000Liters | ||
| Filling Weight | 3192 kg | ||
| Tank Weight | 2540kg | ||
| Thickness of Shell (mm) | 10 mm | ||
| Thickness of End plate (mm) | 10 mm | ||
| Tank Diameter (mm) | 1600 mm | ||
| External Dimensions (mm) (length x width x height) | 4270 x 1620 x 2210 mm | ||
| Material of Tank and Main Pressure Parts | Carbon Steel Q345R | ||
| Filling Medium | Liquefied Petroleum Gas ( Propane) | ||
| Design Pressure | 1.77 MPa / 17.7Bar | ||
| Corrosion Allowance | 1 mm | ||
| Medium Density | 420 kg/ cbm | ||
| Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China. | |||
| Main parts of LPG Tank | |||
| Item | Specification | Quantity | |
| Discharge Pipe | DN80 | 1 | |
| Inflow Pipe | DN80 | 1 | |
| Gas phase balance pipes | DN50 | 2 | |
| Drain Hole | DN50 | 1 | |
| Manhole | DN450 | 1 | |
| Air-out Pipe | DN50 | 1 | |
| Safety Valve Pipe | DN80 | 2 | |
Safety Accessories (Included in the quotation): Cut-off Valve, Needle Valve, Safety Valve, Magnetic Liquid level meter, Pressure gauge, Temperature Gauge. |
|||
Working sence
Filling house for cylinders
Loading for shipment
