Mini Foton Rhd Diesel Petrol Refueling Truck Oil Dispenser Truck 2cbm 2m3 2000liter
2cbm 2m3 2000liter Mini Foton Rhd Diesel Petrol Refueling Truck Oil Dispenser Truck
Product description:
1. Foton Aumark 4X2 right hand driving
2. Cummins diesel engine with 130hp
3. Axle loading: front axle 2.4t rear axle 3.5t
4. 5-Forward & 1-Reverse Z F gear box
5. Q235B carbon steel; Ellipse tank shape
6. 2cbm tank volume with 4mm thickness
Exporting countries:
1. Asia: Nepal, Pakistan, India, Indonesia etc.
2. South America: Anguilla, Bahamas, Grenada, Guyana, Jamaica,Tobago etc.
3. Africa: Kenya, Lesotho, Botswana, Seychelles, Mozambique, Namibia etc.
4. South Africa: Uganda, Zambia, Tanzania, Zimbabwe etc.
Product advantages:
1. Foton chassis with stable, reliable,high quality performance.
2. High pressure gas leakage test to ensure truck's safety.
3. High quality carbon steel material with anti-corrosion
4. Tank body adopts advanced welding technology
5. The tank's surface is painted with sand blasting,derusting treartment,spraying and cleaning technology.
6. We using high quality and imported accessories like pump,carburetor etc.
Product Specification
| Product specification | ||||
| Model | Foton refueling truck | Tank volume | 2000L /2m3 | |
| Overall Dimension(LxWxH) | 5400*1882*2260mm | Driving type | 4X2 RHD | |
| Chassis parameters | ||||
| Chassis | FOTON | |||
| Cabin | single row, allowable for 2 passengers, with Air conditioner | |||
| Engine | Model | ISF2.8s3129T | ||
| Rated power | 130hp | |||
| Displacement | 2.726L | |||
| Type | 4 cylinders in-line, turbo-charged intercooling, direct injection | |||
| Emission | Euro 3, Diesel | |||
| Manufacturer | Cummins | |||
| Tire | Size | 215/75 R17.5, tubeless tire | ||
| Number | 6 tires plus one spare | |||
| Front / Rear axle | 2.4t/3.5t | Rear axle ratio | 4.875 | |
| Fuel tank | 80L, steel | Wheel Base | 2800mm | |
| Tanker parameters | ||||
| Tank volume | 2000L | Tank material | Carbon steel | |
| Shape of the tanker | Ellipse | Tank thickness | 4mm | |
| Tanker outplate | epoxy paint 3 layer inner surface for anti-corrosion | |||
| Transport medium | Diesel oil | |||
| Manhole | GLME, Euro standard, including pressure relief valve | |||
| Bottom Valve | GLME, Euro standard | |||
| Discharge Valve | Aluminium Alloy Ball Valve type (stainless steel ball valve is optional) | |||
| Emergency Cutoff Device | Equipped | |||
| Oil Pump | Weilong or Yifeng (Chinese famous brand ) | |||
| Flow Meter | High-end flow meter | |||
| Filling Gun | Rotary filling gun | |||
| Standard configuration | tool box,climbing ladder, handrail, fire extinguisher, oil hose etc are included | |||
| Optional Configuration | pneumatic valve, AIP valve, overflow sensor system, vapour recovery system | |||
| Color & Logo | Customized | |||
Detailed photos:
Overseas exhibition:
Why choose us:
- Certificate: ASME, ISO, BV, SGS, CCC etc.
- More than 30 independents workshops for different types of trucks
- 1000 sets of equipment, 25 assemble lines.
- 300 senior engineers and technicians and about 8000 staffs
- 800kinds of trucks and semi-trailers with various functions
- 20 years wholesale experience
- Turnover 250 million and Export 20million annually
- More than 100,000 trucks and semi-trailers annually.
- Truck Sold to 90 countries
- Long term cooperation with China leading chassis supplier DONGFENG,SINOTRUCK,FOTON,FAW,BEIBEN,ETC
- We can handle production of bulk order water trucks of tender and government purchase in required time
