340HP Diesel Engine Crude Oil Fuel Tanker Truck Export To Africa Market
340HP Diesel Engine Crude Oil Fuel Tanker Truck Export To Africa Market
CLW GROUP 's full-canopy tank design helps to keep your delivery drivers out of the weather and elements during delivery. Equipment area provides easy access from both sides of the truck.
1. Standard tank capacities from 2,400 - 5,500 gallons; custom sizes available starting at 1300 gallons up to 7,500 gallons
2. Top loading or bottom loading (optional)
3. Single or dual delivery systems
4. Common applications: heating oil, commercial and agricultural deliveries, fleet fueling, oil field deliveries and lubricants
Features:
Tank design with low center of gravity
400 - 7,500 gallon capacity
Heads, baffles and sideshells are formed with a press brake, which allows for precise fit up of components
Fully enclosed equipment area
Removable canopy cover for easier equipment servicing
Equipment access from both sides
LED lighting wired to meet standard
LED work area lights
Product Specifications
| General Technical Parameters | ||||
| Overall Dimension | 10310X2500X3200(mm) |
Gross Vehicle Weight | 28000(kg) | |
| Curb Weight | 10450(kg) | Loading Weight | 18000(kg) | |
| Chassis Specification | ||||
| Chassis Parameters | Chassis Brand | FAW | ||
| Cabin | Row and half, right Hand Driving | |||
| Engine | Power | 340HP | ||
| Emission standard | EURO2 | |||
| Displacement | 10000ml | |||
| Fuel type | Diesel | |||
| Gearbox | 9 Forward & 1 Reverse Gear | |||
| Front and Rear Axle load | 6.5T/13Tx2 | |||
| Wheel Base | 4350+1350(mm) | |||
| Brake System | Pneumatic | |||
| Steering Gear | Power Assistant | |||
| Tire | 11.00R20, 10 Pieces+one spare tire | |||
| Maximum speed | 90(km/h) | |||
| Tank Body | ||||
| Shape | Monoblock Cylinder | |||
| Total Volume(m3) | 18m3 | |||
| Tanker Body Material | 5-6mm carbon steel | |||
| Manhole Cover | ∮500mm ,1 set with 1 breather valve | |||
| Bottom Valve | 1 set | |||
| Discharging Valve | 1 set ∮80mm discharging valve | |||
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint | |||
| Accessories | One standard tool box | |||
Key words:
Fuel bowser truck, fuel tanker truck, oil transport truck, oil truck tanker, light fuel tank truck, truck tank fuel, petrol tanker, petrol fuel tank, diesel dispensing truck, oil delivery truck, Mobile Fuel Truck, oil loading truck, oil refuelling truck, oil transport truck, oil truck tanker, light fuel tank truck, truck tank fuel, petrol tanker, petrol fuel tank, fuel bowser, diesel dispensing truck.
It can be divided into many compartments to transport different medium, which will make your transportation easy and safe.
Open mesh walkway on the right-hand side of the manhole cover, with rear mounted access ladder. Collapsible handrail made of aluminum, fixed as safety barrier, along the dome-pan on top of the diesel tank superstructure. The operation of the handrail is manually, next to the access ladder.
Sales Service
① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.
Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer manual, video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.
Spare Parts
1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. Only charge cost price for customer convenience.
Shipment
Land transportation or Ship by bulk cargo ship, container, roro ship
After Sales Service
Email & Phone call tracking for each truck on timely manners.
