Made in China dual stage argon gas pressure regulator with compression fittings
Made in China dual stage argon gas pressure regulator with compression fittings
R31 Serie stainless steel pressure reducers, doublestage diaphragm pressure reducing construction, stable output pressure, applied to high pure gas, standard gas, corrosive gas and so on.
Features
- five hole design of the body
- double-stage pressure-reducing structure
- Metal-to-metal diaphragm seal
- body thread: input and output connection 1/4” NPT(F)
- easy to clean internal structure
- filter element installed internally
- panel mounting and wall mounting available
- optional outlet: needle valve, diaphragm valve
Technical Data
- Maximum inlet pressure: 3000, 500psig
- output pressure:0~25, 0~50, 0~100, 0~250psig
- safety testing pressure: 1.5 times of maximum inlet pressure
- working temperature: -40~+165 deg F(-40~+74 deg C)
- leakage rate: 2×10-8 atm cc/sec He
- CV value=0.06
Application
- laboratory
- gas chromatography
- gas lasers
- gas bus-bar
- petrochemical industry
- testing equipment
Material
- body: 316L, Brass
- bonnet: 316L, Brass
- diaphragm: 316L
- strainer: 316L(10μm)
- seat: PCTFE, PTFE, Vespel
- spring: 316L
- stem: 316L
| Item | Body Material | Body Hole | Inlet pressure | Outlet pressure | Gauge | Inlet connection | Outlet connection | Optional |
| R31 | L:ss316L | M | D:3000PSI | G:0-125psi | G:Mpa | 00:1/4NPT F | 00:1/4"NPT F | P:panel mount |
| B:brass | Q | F:500PSI | I:0-75psi | P:psi/bar | 01:1/4"NPT M | 01:1/4"NPT M | R:attached safety relief valve | |
| K:0-25psi | W:no gauge | 23:CGA330 | 10:1/8O.D. | N:attached needle valve | ||||
| L:0-15psi | 24:CGA350 | 11:1/4O.D. | D:attached diaphragm valve | |||||
| Q:30"Hg Vac-30psig | 27:CGA580 | 12:3/8O.D. | ||||||
| S:30"hg Vac-60psig | 28:CGA660 | 15:6mmO.D. | ||||||
| T:30"hg Vac-100psi | 30:CGA590 | 16:8mmO.D. | ||||||
| U:30"Hg Vac-200psi | 52:G5/8"-RH(F) | 74:M8*1-RH(M) | ||||||
| 63:W21.8-14H(F) | ||||||||
| 64:W21.8-14LH(F) | ||||||||
