High Flow 1Inch Stainless Steel Pressure Regulator , Adjustable Pressure Relief Valve
Design Features
- Single-stage pressure-reducing structure
- Diaphragm with Nylon and NBR two layers construction
- Body thread: inlet and outlet connection1” NPT(F)
- Pressure gauge connection: 1/4" NPT(F)
- Panel mounting and wall mounting available
Specification
- Maximum inlet pressure: 500psig
- Output pressure: 0~25, 0~50, 0~100,0~125, 0~250psig
- Safety testing pressure: 1.5 times of maximum inlet pressure
- Working temperature: -10~+250 deg F(-23~+121 Deg C)
- Leakage rate: bubble tight
- Cv value=5.1
MATERIAL
| 1 | Body | 316L,Brass |
| 2 | Bonnet | 316L,Brass |
| 3 | Diaphragm | NBR(Nylon inside) |
| 4 | Seat | NBR |
| 5 | Spring | 316L |
| 6 | Stem | 316L |
ORDERING INFORMATION
| Item | L | B | F | G | G | 06 | 06 |
| R61 | L:316 | Body Hole | Inlet Pressure | Outlet Pressure | Pressure Gauge | Inlet Size | Outlet Szie |
| B:Brass | A | F:500psig | G:0~250psig | G:MPa gauge | 06:3/4"NPT(F) | 06:3/4"NPT(F) | |
| B | H:0~125ig | P:Psig/bar gauge | 07:3/4"NPT(M) | 07:3/4"NPT(M) | |||
| G | I:0~100psig | W:No gauge | 08:1"NPT(F) | 08:1"NPT(F) | |||
| K:0~50psig | 09:1"NPT(M) | 09:1"NPT(M) | |||||
| L:0~25psig |
Product Packaging
Company profile
FAQ
Q: Are you trading company or manufacturer?
A: We are original manufacturer. We can do OEM/ODM business.Our company mainly produces Pressure Regulator.
Q: How long is your delivery time?
A: Group buying delivery time: 30-60 days; General delivery time: 20 days.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q: What is the warranty ?
A: The free warranty is one year from the day of Commissioning qualified.If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
