Description One

*Medium:Water
*Temperature: Suitable water≤42℃, surroundings≤52℃
*Application range: It is currently one of the most widely used electromagnetic valve in garden irrigation, large-scale garden lawn, stadium, farm, industrial dust and water treatment equipment.

Description Two

*Model: 200P
*Pressure: 0.1~1.0Mpa
*Connect size: 2"
*Thread: G
*Orifice size: 50mm
*Coil: AC220, AC110V, AC24V, 50/60HZ, 10VA
*Self-holding type coil: DC6-20V, Pulse Width (20-500mSec)
*Working model(+red&-black valve open)
                           (-red&-black valve closed)

Description Three

*Material-body valve -nylon enclosed-NBR
*Moving iron core-430F
*Static iron core-430F
*Sping-SUS304 Sub-magnetic ring-Copper

*Water treatment solenoid, normally closed, coil AC24V, Self-holding type coil DC6-20V (Please specify when ordering)
