Plastic 40mm 1.5 inch Irrigation Solenoid Valve DC Latching for Water
One
Medium:Water
Temperature: Suitable water≤42℃, surroundings≤52℃
Application range: It is currently one of the most widely used electromagnetic valve in garden irrigation, large-scale garden lawn, stadium, farm, industrial dust and water treatment equipment.
Two
Model: 150P
Pressure: 0.1~1.04Mpa
connect size: 1.5"
Thread: G
Coil: AC220, AC110V, AC24V, 50/60HZ, 10VA
Orifice size: 40mm
Self-holding type coil: DC6-20V, Pulse Width (20-500mSec)
working model(+red&-black valve open)
(-red&-black valve closed)
Three
Material-body valve -nylon
enclosed-NBR
Moving iron core-430F
Static iron core-430F
Spring-SUS304
Sub-magnetic ring-Copper
