DC Electric Irrigation Valve Low Pressure Nylon Body Material With NPT Connector

Price Negotiable

Price: Negotiable

MOQ: 10-49 Pieces

Delivery Time: Negotiable

Brand: AFK

Product Description

DC low pressure 9v direct acting water solenoid valve Normally Closed

Specification

1.The pilot type diaphragm structure , nylon body material.

2. Double filter to prevent clogging eletromagnetic core.

3.Fully enclosed eletromagnrtic coil, waterproof.

4.A slow off function to prevent water harmmer, damage the system.

No.	ITEM	TECHNICAL PARAMETERS
1	material	nylon plastic body, NBR seal
2	Fluid	water
3	Fluid temperature	≤43°C
4	Environment temperature	≤52°C
5	Service voltage	6-20VDC(can be order latching type coil), 24VAC, 24VDC, 110VAC, 220VAC
6	Pulse width	20-500mSec (only for latching type)
7	Coil resistance	6 Ω
8	Capacitance	4700uF
9	Coil inductance	12mH
10	Connection	G(BSP) female thread is regular, special order for NPT(3/4" and 1")
11	Size	075D: 3/4", 20mm (BSP or NPT female) 100D:1", 25mm (BSP or NPT female ) 100P:1", 25mm (BSP female) 150P:1-1/2"(1.5"), 40mm (BSP female) 200P:2", 50mm (BSP female) 300P:3", 80mm (BSP female, male, flange) 400P:4", 100mm (BSP female, male, flange)
12	Working pressure	3/4" and 1": 1-10bar 1.5"and 2": 1-10.4bar 3"and 4": 0.7-14bar
13	Flow rate	3/4": 5 m³/h 1": 9 m³/h 1.5"-2": 0.45-34.05 m³/h 3"-4": 1.1-70 m³/h
14	Operation mode	valve element lock position,valve open, release position, valve close.
