Low Pressure Argon Stainless Steel Gas Pressure Regulator AFK Brand Inlet 500 1500psi
AFK Brand Inlet 500,1500psi Low Pressure Argon Stainless Steel Gas Pressure Regulator
R13 Series stainless steel pressure reducers, single-stage diaphragm pressure reducing construction, stainless steel diaphram pressure transmission, stable output pressure, applied in mass flow gas system for pure gas, standard gases, standard gases and corrosive gas etc..
Argon gas pressure regulator Materials
| 1 | Body | 316L, brass ( Weight: 2.7kg) |
| 2 | Bonnet | 316L, brass |
| 3 | Diaphragm | 316L |
| 4 | Strainer | 316L(10um) |
| 5 | Seat | PCTFE, PTFE, Vespel |
| 6 | Spring | 316L |
| 7 | Stem | 316L |
argon gas pressure regulator Specifications
| 1 | Maximun inlet pressure | 500,1500 psig |
| 2 | Output pressure | 0~15, 0~25, 0~75, 0~125 psig |
| 3 | Safety testing pressure | 1.5 times of maximum inlet pressure |
| 4 | Working temperature | -40°F~ +165°F (-40°C~ +74°C ) |
| 5 | Leakage rate | 2×10-8 atm cc/sec He |
| 6 | CV | 1.8 |
1) Single -stage pressure-reducing Structure.
2) Metal-to-metal diaphragm seal.
3) Body Thread : input & output connection 3/4" NPT ( F )
4) Gauge and safety valve connection: 1/4" NPT ( F )
5) Filter element installed internally
6) Panel mountable or wall mounting available
7)Easy to clean internal structure
Detailed Images
Ordering Information
| R13 | L | B | E | H | G | 04 | 04 | P |
| Item |
Body Materia |
Body hole |
Inlet pressure |
Outlet pressure | Pressure gauge | Inlet size | Outlet size | Options |
| R13 | L:316 | A | E:1500psi | H:0~125psig | G:MPa gauge | 04:1/2”NPT(F) | 04:1/2”NPT(F) | P:Panel mounting |
| B:Brass | B | F:500psi | J:0~75psig | P:Psig/bar gauge | 05:1/2”NPT(M) | 05:1/2”NPT(M) | R:With relief valve | |
| D | L:0~25psig | W:No gauge | 06:3/4”NPT(F) | 06:3/4”NPT(F) | ||||
| G | M:0~15psig | 13:1/2”OD | 13:1/2”OD | |||||
| J | 14:3/4”OD | 14:3/4”OD | ||||||
| M | Other type is available | Other type is available |
Product Show
Our Company
Packing & Delivery
Payment Terms
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: No, we not offer the sample for free charge and also not pay the cost of freight.
Q: What is your payment ?
A: T/T , PayPal , Western Union
