Normally Open Water Solenoid Valve Pilot Type Brass 2 Way For Water Gas Oil 11/2"
Normally Open Pilot Type Brass 2 way Solenoid Valve China Manufacture Used for Water Gas Oil 11/2"
Charateristic:
Direct-acting diaphragm tpy electric olose type
The valve boay is brass foring
Working pressure:1-10KGF/CM
Rated voltage:AC110v/AC220V/DC24V(50/60HZ)
Voltage tolerance:±10%DC voltage tolerance:±10%
Data sheet
|
Model No. |
2W-06K |
2W-08K |
2W-160-10K |
2W-15K |
2W-20K |
2W-25K |
2W-32K |
2W-40K |
2W-50K |
|
Pipe Size |
1/8" |
1/4" |
3/8" |
1/2" |
3/4" |
1" |
1-1/4" |
1-1/2" |
2" |
|
Orifice Size |
2.5mm |
4mm |
16mm |
16mm |
20mm |
25mm |
32mm |
40mm |
50mm |
|
Fluid |
air, water, oil, neutral gas and liquid |
Service Voltage |
DC12V 24V / AC110V 220V (50/60Hz) ±10% |
||||||
|
Operating Mode |
Polit type |
Type |
normally open |
||||||
|
Body Material |
forged brass, stainless steel 304 |
Working Pressure |
1-10bar |
||||||
|
Sealing Material |
NBR: fluid temperature <80°C VITON: fluid temperature<150°C |
||||||||
Related product
|
Model No. |
2W-025-06 |
2W-025-08 |
2W-040-10 |
2W-160-10 |
2W-160-15 |
2W-200-20 |
2W-250-25 |
2W-320-32 |
2W-400-40 |
2W-500-50 |
|
Pipe Size |
1/8" |
1/4" |
3/8" |
1/2" |
3/4" |
1" |
1-1/4" |
1-1/2" |
2" |
|
|
Orifice Size |
2.5mm |
4mm |
4mm |
16mm |
16mm |
20mm |
25mm |
32mm |
40mm |
50mm |
|
Cv Value |
0.23 |
0.6 |
4.8 |
4.8 |
7.6 |
12 |
24 |
29 |
48 |
|
|
Fluid |
air, water, oil, neutral gas and liquid |
|||||||||
|
Service Voltage |
AC380V AC220V AC110V DC24V DC12V (allow ±10%) |
|||||||||
|
Operating Mode |
direct acting |
Type |
normally closed |
|||||||
|
Body Material |
brass |
Fluid Viscosity |
<20CST |
|||||||
|
Working Pressure |
water and air: 0-10bar oil: 0-7bar |
|||||||||
|
Sealing Material |
NBR: fluid temperature <80°C EPDM: d temperature<120°C VITON: fluid temperature<150°C |
|||||||||
