Two Gauges Single Stage Pressure Regulator Valve Neoprene Diaphragm For Natural Gas
Brass Single Stage Pressure Regulator Valve with two gauges used for Natural Gas
R57 Series brass single stage type pressure regulator, widely suitable for middle flow gas demand occasions,
including Gas welding cutting, industrial manufacturing, agricultural maintenance, laboratory testing and other occasions.
1) Model: R57 Gas Pressure Regulator
2) Outlet pressure: 15 Mpa
3) Gauge: Two
4) Inlet connection: G5/8"-RH(F)
5) Outlet connection: M16-1.5RH(M)
Product Selection
| Model | Application Gas | Max.Inlet Pressure(MPa) | Outlet Pressure(MPa) | Inlet Gauge(Mpa) | Outlet Gauge(Mpa) | inlet thread | outlet thread |
| R57X-15 | O2 | 15 | 0.01~0.1 | 25 | 0.25 | G5/8"-RH(F) | M16-1.5RH(M) |
| R57X-40 | 15 | 0.01~0.28 | 25 | 0.4 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57X-80 | 15 | 0.02~0.56 | 25 | 1 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57X-125 | 15 | 0.03~0.85 | 25 | 1.16 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57X-175 | 15 | 0.02~1.7 | 25 | 2.5 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57Y-15 | acetylene | 3 | 0.01~0.1 | 4 | 0.25 | Bottle receiving rack | M16-1.5RH(M) |
| R57F-40 | Propane, natural gas | 3 | 0.01~0.28 | 4 | 0.4 | M22-1.5LH(M) | M16-1.5RH(M) |
| R57F-80 | 3 | 0.02~0.56 | 4 | 1 | M22-1.5LH(M) | M16-1.5RH(M) | |
| R57F-125 | 3 | 0.03~0.85 | 4 | 1.6 | M22-1.5LH(M) | M16-1.5RH(M) | |
| R57IN-15 | Argon, helium, nitrogen | 15 | 0.01~0.1 | 25 | 0.25 | G5/8"-RH(F) | M16-1.5RH(M) |
| R57IN-40 | 15 | 0.01~0.28 | 25 | 0.4 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57IN-80 | 15 | 0.02~0.56 | 25 | 1 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57IN-125 | 15 | 0.03~0.85 | 25 | 1.6 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57IN-175 | 15 | 0.02~1.7 | 25 | 2.5 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57Q-15 | Ari | 15 | 0.01~0.1 | 25 | 0.25 | G5/8"-RH(F) | M16-1.5RH(M) |
| R57Q-40 | 15 | 0.01~0.28 | 25 | 1.4 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57Q-80 | 15 | 0.02~0.56 | 25 | 1 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57Q-125 | 15 | 0.03~0.85 | 25 | 1.6 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57Q-175 | 15 | 0.02~1.7 | 25 | 2.5 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57H-40 | H2 | 15 | 0.01~0.28 | 25 | 0.4 | W21.8-14LH(F) | M16-1.5RH(M) |
| R57H-80 | 15 | 0.02~0.56 | 25 | 1 | W21.8-14LH(F) | M16-1.5RH(M) | |
| R57H-80-V | 15 | 0.02~0.56 | 25 | 1 | W21.8-14LH(F) | M16-1.5RH(M)With regulating valve | |
| R57H-125 | 15 | 0.03~0.85 | 25 | 1.6 | W21.8-14LH(F) | M16-1.5RH(M) | |
| R57H-175 | 15 | 0.02~1.7 | 25 | 2.5 | W21.8-14LH(F) | M16-1.5RH(M) | |
| R57C-40 | CO2 | 15 | 0.03~0.85 | 25 | 0.4 | G5/8"-RH(F) | M16-1.5RH(M) |
| R57C-80 | 15 | 0.02~0.56 | 25 | 1 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57C-125 | 15 | 0.03~0.85 | 25 | 1.6 | G5/8"-RH(F) | M16-1.5RH(M) | |
| R57C-175 | 15 | 0.02~1.7 | 25 | 2.5 | G5/8"-RH(F) | M16-1.5RH(M) |
Packing & Delivery
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
FAQ
Q1. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q2. Do you have any MOQ limit ?
A: Low MOQ 1 pic.
Q3. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 5-7 days. Airline and sea shipping also optional.
Q4. How to proceed an order ?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
