Industrial 1000psi Stainless Steel Pressure Regulator 1.8CV Single Stage Diaphragm Type
AFK Stainless Steel Industrial Oxygen/Hydrogen/Nitrogen/Argon Gas Cylinder Regulator Valve 1000psi
|
R13 series stainless steel pressure reducer , single-stage diaphragm pressure reducing structure , satinless steel diaphragm pressure transmission , stable output pressure , mainly decomposes large flow gas systems , suitable for pure gas , standard gas , corrosive gas , etc |
Design Features
| 1 |
Single-stage pressure-reducing structure |
| 2 |
Metal-to-metal diaphragm seal |
| 3 |
Body thread : input & output connection 3/4”NPT(F) |
| 4 |
Gauge and safe valve connection : 1/4”NPT(F) |
| 5 |
Easy to clean internal structure |
| 6 |
Filter element installed internally |
| 7 |
Panel mounting and wall mounting available |
Material
| 1 |
Body |
316L , Brass |
| 2 |
Bonnet |
316L , Brass |
| 3 |
Diaphragm |
316L (10μm) |
| 4 |
Strainer |
316L |
| 5 |
Seat |
PCTFE , PTFE . Vespel |
| 6 |
Spring |
316L |
| 7 |
Stem |
316L |
Ordering Information
| R13 | L | B | E | H | G | 04 | 04 | P |
| Item |
Body Materia |
Body hole |
Inlet pressure |
Outlet pressure | Pressure gauge | Inlet size | Outlet size | Options |
| R13 | L:316 | A | E:1500psi | H:0~125psig | G:MPa gauge | 04:1/2”NPT(F) | 04:1/2”NPT(F) | P:Panel mounting |
| B:Brass | B | F:500psi | J:0~75psig | P:Psig/bar gauge | 05:1/2”NPT(M) | 05:1/2”NPT(M) | R:With relief valve | |
| D | L:0~25psig | W:No gauge | 06:3/4”NPT(F) | 06:3/4”NPT(F) | ||||
| G | M:0~15psig | 13:1/2”OD | 13:1/2”OD | |||||
| J | 14:3/4”OD | 14:3/4”OD | ||||||
| M | Other type is available | Other type is available |
FAQ
Q: Are you trading company or manufacturer?
A: We are original manufacturer. We can do OEM/ODM business.Our company mainly produces Pressure Regulator.
Q: How long is your delivery time?
A: Group buying delivery time: 30-60 days; General delivery time: 20 days.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q: What is the warranty ?
A: The free warranty is one year from the day of Commissioning qualified.If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
