Product Definition
The M19 Series Power Connector is a robust, circular waterproof power connector designed for reliable power transmission in demanding environments. Available in male (plug) and female (socket) versions, it features a 3-pin + PE (protective earth) configuration, supporting up to 300V DC / 20A. With an IP-rated sealed design, threaded coupling, and high-grade materials, the M19 series delivers excellent waterproof, dustproof, and corrosion-resistant performance for industrial and outdoor applications.
Key Features
- High Power Capacity: Rated 300V DC / 20A – ideal for medium-power equipment
- Excellent Environmental Resistance: Operates in -25°C to +70°C with 90% humidity tolerance and passes 72-hour salt spray test
- Superior Safety & Reliability: AC2000V dielectric withstand voltage, ≥100MΩ insulation resistance, and low contact resistance (≤10mΩ)
- Secure Locking: Threaded coupling + spring-loaded design ensures vibration-proof and reliable connection
- Ultra Low Insertion Force: Only 10.40N — significantly easier to connect/disconnect than competitors
- Free Testing Service: We provide free sample testing, technical verification, and customized reports to support your project
M19 Series Power Connector Table
| Parameter | Specification |
| Rated Voltage | DC 300V |
| Rated Current | 20A |
| Contact Resistance | ≤ 10 mΩ |
| Insulation Resistance | ≥ 100 MΩ |
| Withstand Voltage | AC 2000V (50Hz) / 1 min |
| Insertion Force | 10.40 N |
| Durability | ≥ 3000 mating cycles |
| Operating Temperature | -25°C ~ +70°C |
| Relative Humidity | 90% (40°C) |
| Salt Spray Test | 72 hours |
| Pin Configuration | 3 Power + PE (4 pins total) |
| Coupling | Threaded screw coupling |
| Housing Material | High-performance engineering plastic + metal options |
| Contact Material | Gold-plated copper |
Application Scenarios
- Industrial Equipment: Automation machinery, control cabinets, motors, pumps
- New Energy: Solar inverters, energy storage systems, EV charging stations (low voltage)
- Outdoor Lighting: LED floodlights, street lights, architectural lighting
- Transportation: Electric vehicles, rail transit, marine equipment
- Telecom & 5G: Base stations, communication power supplies
- Agricultural & Construction: Farm machinery, heavy equipment, temporary power
- Smart Home / Commercial: High-power appliances, outdoor power distribution
