N Female Bulkhead With O-ring Connector to UFL 20cm Length 1.13mm Coaxial Cable Assembly
Price:
Negotiable
MOQ:
100 PCS
Delivery Time:
1-2weeks
Brand:
sun Communication
Product Description
N Female Bulkhead With O-ring Connector to UFL 20cm Length 1.13mm Coaxial Cable Assembly
Similiar product:
SMA TO MMCX Cable
MMCX SMA cable
sma male to Female Cable
bnc to SMA cable
tnc to sma male cable
sma RF cable RG316
Materials and plating
| Description | Materials | Plating |
| Body | Stainless steel | Passivation |
| Contact pin | Beryllium copper C17300 | Gold Plating |
| Insulator | PTFE ASTM-D-1710 | N/A |
Specification
| Electrical parameters | |
| Impedance | 50 Ohm |
| Frequency range | DC~18GHz |
| Voltage rating | 500 V(rms) |
| Dielectric withstanding voltage | >1500V |
| Center contact resistance | <1.0mΩ |
| Outer contact resistance | <0.2mΩ |
| Insulation resistance | >5000MΩ |
| Insertion loss | <0.10 sqrt(f(GHz)) dB |
| VSWR | <1.30 |
| Mechanical parameters | |
| Center contact retention force | >20 N |
| Durability | >500 cycles |
| Environmental parameters | |
| Temperature range | -55 ℃~+155 ℃ |
| Thermal shock | MIL-STD-202, Meth. 107, Cond. B |
| Corrosion | MIL-STD-202, Meth. 101, Cond. B |
| Vibration | MIL-STD-202, Meth. 204, Cond. D |
| Shock | MIL-STD-202, Meth. 213, Cond. I |
| Interface | |
| According to | MIL-STD-348, IEC 60169-16 |
