500*500mm Cuboid Bale Size Turn Over Bale Out Metal Baler Machine
500*500mm Cuboid Bale Size Turn Over Bale Out Metal Baler Machine
About the metal baler machine
In real life, there are various kinds of scrap metals with different sizes, which is a big problem in storage, transportation and smelting in steel mills. Moreover, the long-term retention of scrap metals will cause slight air pollution, and long-term storage will occupy space and cause harm to the body. There are many ways to deal with scrap metal, because scrap metal is a living resource. Recycling can produce new steel, which can be put into the market again and recycled. In this way, a lot of resources can be saved, and the mining of the earth's mining resources will also be protected. Our company metal baler machine can pack all kinds of scrap metal into lump iron which is convenient for storage, transportation and smelting
Metal baler machine can extrude various kinds of relatively large scrap metal, scrap steel, scrap iron, scrap copper, scrap aluminum, disintegrate car shell, waste oil drum into cuboid, cylinder, octagonal shape and other qualified furnace charge. In order to facilitate storage, transportation and recycling. After being put into the furnace, the pressing loss is lower. The whole production process does not need heating, additives or other processes, direct cold pressing molding, forming at the same time also ensure the original material unchanged. For example, cast iron scrap is used instead of cast pig iron after forming. For castings of special material, recycling is more significant.
| Model | 2500 |
| Nominal pressure | 250T |
| Power | 30kw+30kw |
| Pump | YCY-160+ YCY-160 |
| Material box size | 2500*2000*1000mm |
| Bale size | 500*500mm |
| Bale-out mode | Turn over / manual Note: Full automatic operation can be configured |
| Bale density | ≥2200kg/m3 |
| Production efficiency | 40-50 Ton / 8 hours |
Working process of metal baler machine
The raw material is placed in the material box of the scrap metal baler, and the hydraulic cylinder works to press, and the packing material is compressed into various kinds of metal lumps.
Application of metal baler machine
Application scope: waste recycling station, recycling center, enterprise customers, steel plant
Materials: iron / steel: scrap iron, light and thin materials, scrap, car shell, scrap, waste oil bucket, bicycle frame, lathe chips, shavings, iron chips, steel chips, color steel tiles, stainless steel.
Scrap aluminum: aluminum chips, aluminum shavings, aluminum profiles, doors and windows, cans, aluminum foil, aluminum alloy.
Scrap copper: copper wire, copper plate, copper scrap, copper shavings, copper wire
Features of metal baler machine
1. All models are driven by hydraulic pressure and can be operated manually or controlled automatically by PLC.
2. The methods of bale-out include turning, side pushing, forward pushing and manual picking.
3. A variety of models are available: different pressure, material box size, bale size and shape.
4. Where there is no power supply, diesel engine can be used as power.
5. It is safe and reliable, easy to operate and maintain.
Use metal baler machine:
1. After pressing, the transportation of metal is convenient, which can reduce the transportation cost and increase the transportation efficiency;
2. After pressing, the metal is easy to be broken for secondary treatment;
3. Compared with metal, pressed metal is easier to store and can save warehouse space;
4. The pressed metal is convenient for use and reprocessing.
