Stainless Steel 220V/380V 6000LPH RO Water Treatment System For Drinking/ Beverage

Price Negotiable
Price: negotiation
MOQ: negotiation
Delivery Time: 15-30working days(depand on raw materials stocking)
Brand: Kaiyuan
Product Description

Stainless Steel 220V/380V 6000LPH RO Water Treatment System For Drinking/ Beverage


Industrial Reverse Osmosis systems remove up to 99.9% of salts and contaminates from different impure feed water sources including municipal, brackish and surface water. The system blocks bacteria, particles, sugars, proteins, dyes, and impurities that encompass a molecular weight of more than 150-250 Dalton.



Industrial Reverse Osmosis RO Water Treatment Process

►Industrial reverse osmosis plant includes a multimedia prefilter, water softener or antiscalant dosing system(optional), dechlorination dosing system, reverse osmosis unit with semi-permeable membranes, and UV sterilizer or post chlorination as a post treatment.

►These RO machines apply the technology of reverse osmosis by transporting feed water through a multimedia prefilter to remove particles that are larger than 10-micron.

►Then the water is injected by an antiscalant chemical to control hardness fouling that may cause damage to the membranes of the RO machine. These pretreatment options have the capability of removing hardness, chlorine, odors, color, iron, and sulfur.

►The water then continues into the reverse osmosis unit where a high-pressure pump applies extreme pressure to the highly concentrated solution, separating the remaining salts, minerals, and impurities that the pre-filter cannot catch.

►Fresh, potable water comes out from the low-pressure end of the membrane while salts, minerals, and other impurities are discharged into a drain on the other end.

►Lastly, the water is passed through a UV sterilizer (or post chlorination) to kill any bacteria and microbes that still exist in the water.



Applications

Industries such as chemical and pharmaceutical manufacturing, food and beverage processing, and waste water treatment, employ ultrafiltration in order to recycle flow or add value to later products. Blood dialysis also utilizes ultrafiltration.


  • Filtration of effluent from paper pulp mill
  • Removal of some bacterias from milk
  • Process and waste water treatment
  • Enzyme recovery
  • Fruit juice concentration and clarification
  • Fruit juice concentration and clarification
  • Laboratory grade manufacturing
  • Radiocarbon dating of bone collagen

Kaiyuan leads the way in the reliable production of membrane systems for high-quality potable and process water. Efficiently designed low-pressure membrane filtration (ultrafiltration / microfiltration) systems use hollow fiber membranes with small pore sizes (0.01-0.1 µm) to reliably produce high quality water using an absolute barrier.

Thank you so much for your value time.Any questions please click "contact now" send us inquiry !We will reply you within 24 hours. Tel/whatsapp/wechat: +86-13660858152

Guidelines for getting a proper quotation
Tell us the raw water/source of water
Provide water analysis report
Required production capacity( 500 liters per hour, 1000liters per hour…)
What's the pure water used for( drinking, bottle water or industrial use…)
