50Ω SMPM Male PCB Connector 0.3MHz-40GHz 170V
Price:
The price depend on the quantity
MOQ:
MOQ 100 pieces
Delivery Time:
8-12 weeks for new production
Brand:
ELT
Product Description
50Ω Hermetically Sealed with Glass SMPM Male for PCB Soldering RF Coaxial Connector 0.3MHz-40GHz
The SMPM coaxial connector features a compact design optimized for small package requirements while delivering exceptional shielding to minimize signal interference. This ensures high-speed data transmission with minimal loss. When paired with an SMPM female to female adapter, it provides reliable board-to-board connections while compensating for radial and axial misalignments during installation. Ideal for precision applications requiring high performance in advanced interconnect systems.
Key Features
- Physical Separation: Isolates spaces at both connector ends (device interior/exterior or separate cavities) to prevent electromagnetic interference and environmental effects (dustproof, waterproof)
- Stable Fixation: Secures connector position against vibration or insertion/removal forces, maintaining consistent signal transmission
Product Specifications
| Item | Value |
|---|---|
| Product Name | SMPM Male PCB Connector |
| Model | SSMP(M)-JHD84 |
| Frequency Range | 0.3MHz-40GHz |
| Impedance | 50Ω |
| Rated Voltage | 170V |
| DWV | 500V |
| Insulation Resistance | ≥5000MΩ |
| Center Conductor | Kaval Alloy, Gold Plated |
| Outer Conductor | Kaval Alloy, Gold Plated |
| Insulation Dielectric | Glass |
Product Outline Dimensions (Unit: mm)
Note 1: Hermetic | Note 3: Engagement Depth 1.7
Note 1: Hermetic | Note 5: Engagement Depth 2.11
Applications
- Microwave communication systems
- Measurement equipment
- Aerospace applications
- Radar systems
- Electronics fields
Elite Electronic manufactures SMPM connectors using premium materials and rigorous quality control processes to ensure exceptional durability and reliability in extreme environments.
Packaging & Shipping
Each SMPM bulkhead connector is carefully packaged in protective cartons to ensure safe transit. We use reliable courier services with tracking numbers provided for all shipments.
For model availability and additional series options, please contact us at sales3@xa-elite.com.cn.
Note: While some models are in stock, all catalog-listed models can be produced quickly upon request.
