Product Description:

The SMP RF Connector is a high-performance solution designed to meet the demanding requirements of modern RF and microwave applications. Engineered with precision and reliability in mind, this connector is ideal for use in environments where signal integrity and minimal loss are critical. The SMP Male Connector is specifically designed to provide excellent electrical performance up to a frequency range of DC to 40 GHz, making it suitable for a wide array of communication systems, test equipment, and aerospace applications.

In addition to its mechanical robustness, the SMP RF Connector Voltage Standing Wave Ratio (VSWR) of less than 1.3 across its operating frequency range. A low VSWR value indicates minimal signal reflection and efficient power transfer, which is critical in high-frequency RF applications. This performance metric ensures that the SMP RF Connector maintains signal quality and reduces signal loss, which is essential for maintaining system performance and reliability.

Technical Parameters:

Applications:

The SMP RF coaxial connector is widely utilized in telecommunications infrastructure, including cellular base stations and satellite communication systems, where reliable high-frequency signal transmission is critical. Its compact size make it perfect for integration into complex RF assemblies and test equipment which is essential in harsh enviroments.

Whether for use in test and measurement equipment, wireless communication devices, or other high-frequency signal applications, the Elite Electronics SMP RF coaxial connector combination of high-frequency performance, robust construction, and flexible ordering options makes it an excellent choice for engineers and procurement specialists seeking reliable SMP connectors.

Customization:

Elite Electronics offers customized SMP RF Connector solutions, including the Flange Mount SMP Connector, SMP RF Connector mating cable, and SMP through hole PCB mount connector, designed to meet diverse application needs in aerospace, aviation, navigation, satcom, telemetry, remote control, radar, and 5G base stations.

Packing & Shipping:

Our SMP RF Connectors are carefully packaged to ensure maximum protection during transit. Each connector is individually sealed in anti-static bags to prevent damage from electrostatic discharge. The connectors are then placed in custom foam inserts within sturdy cardboard boxes to avoid any movement and impact.

For shipping, we use reliable carriers with tracking options to provide timely delivery and shipment visibility.  All shipments are handled with care to maintain product integrity and arrive in perfect condition.

FAQ:

Q1: What brand is the RF Connector?

A1: The SMP RF Connector is manufactured by Elite Electronics and the brand is ELT.

 Q2: Where is the RF Connector made?

A2: The SMP RF Connector is produced in Xi'an, China.

 Q3: What certifications does the the SMP RF Connector have?

A3: The SMP RF Connector is certified with Rohs, ISO 9001, and ISO 14001.

Q4: What is the minimum order quantity and packaging details for this product?

A4: The MOQ is 50 pieces, but there is no MOQ restriction if the product have stocks. Packaging includes 1 piece per plastic bag and 10 bags per larger plastic bag, 100 pcs per carton.

Q5: What are the payment terms and delivery time for the SMP RF Connector?

A5: Payment can be made via T/T or LC. Delivery time is typically 5-7 working days for stocked quantities.
