18GHz SMP Male Plug RF Coaxial Connector Limited Detent Thru Hole Solder Attachment Flange Mount for Telemetry Equipment & Radar Systems

Product Description:

SMP Connectors: The Ideal Choice for Reliable Interconnection in Compact, High-Performance Electronic Systems

Our SMP series connectors deliver exceptional RF performance and mechanical stability. Featuring a push-on interface design, they simplify installation—perfect for space-constrained board-to-board (PCB) or blind-mate configurations.

• Ultra-Wideband Performance: Supports operating frequencies up to 18 GHz, even 40 GHz, ensuring signal integrity and minimal loss in telemetry transmission.
• High-Density Packaging: Compact structure enables ultra-high mounting density, ideal for miniaturized radar and telemetry systems.
• Multiple Retention Options: Available in smooth bore, limited detent, and full detent interfaces—ideal for frequent mating cycles in test environments or vibration-resistant industrial applications.
• Robust Environmental Resistance: Rugged design withstands extreme temperature fluctuations and intense vibration, maintaining stable performance in harsh electromagnetic and physical conditions.
• Flexible Mounting Solutions: Compatible with cable, flange, and through-hole PCB mounting—adaptable to diverse PCB layout requirements.

From aerospace telemetry and phased array radar to high-end test & measurement equipment, our SMP connectors provide efficient, reliable interconnect solutions for the most demanding modern electronic systems.

Technical Parameters:

Applications:

The Elite Electronics SMP RF Connector stands out as a trusted component for engineers and technicians working in aerospace, radar, satellite, and telecommunications industries.

Customization:

ELT offers customized solutions for our High Frequency SMP Connector series. Our SMP connectors, including SMP Female Connector and SMP Male Connector variants, are designed to operate efficiently in a frequency range of DC~40GHz, ensuring superior performance for your high-frequency applications.

Our products are certified with Rohs, ISO 9001, and 14001, reflecting our commitment to quality and environmental standards.

The minimum order quantity is 50pcs for our normal models; however, there is no MOQ restriction if the product is in stock.

MOQ for Customization: 200pcs

Packing & Shipping:

Our SMP RF Connectors are carefully packaged to ensure maximum protection during transit. Each connector is individually sealed in anti-static bags to prevent damage from electrostatic discharge. The connectors are then placed in custom foam inserts within sturdy cardboard boxes, providing cushioning against shocks and vibrations.

For shipping, we use reliable courier services that offer tracking and insurance options to guarantee safe and timely delivery. Multiple connectors are shipped in bulk packaging with additional padding to minimize movement and potential impact. We also offer expedited shipping options for urgent orders.

All packages are clearly labeled with product information, handling instructions, and destination details to facilitate smooth customs clearance and delivery. Our packaging and shipping processes adhere to international standards to ensure that your SMP RF Connectors arrive in perfect working condition.

FAQ:

Q1: What is the brand and model number of this RF connector?

A1: The RF connector is branded ELT.

Q2: Where is the SMP RF Connector manufactured?

A2: It is manufactured in Xi'an, China.

Q3: What certifications does the ELT SMP RF Connector have?

A3: The connector is certified with Rohs, ISO 9001, and ISO 14001.

Q4: What is the minimum order quantity and packaging details for this product?

A4: The minimum order quantity is 50 pieces, but there is no MOQ restriction if the item is in stock. The packaging includes 1 piece per plastic bag and 10 bags per carton.

Q5: What are the delivery time and payment terms for ordering the SMP RF Connector?

A5: Delivery time is typically 5-7 working days for stocked quantities. Payment can be made via T/T or LC.
