40 GHz SMP Plug Limited Full DetentRF Coaxial Connector PCB Mount for Radar Detection & Telecommunication
Product Description:
SMP Connectors: The Ideal Choice for Reliable Interconnection in Compact, High-Performance Electronic Systems. Our SMP series connectors offer outstanding RF performance and mechanical robustness. With a push-on interface design, they facilitate easy installation, making them ideal for space-limited board-to-board (PCB) or blind-mate setups.
Key Features:
- Ultra-Wideband Capability: Operates at frequencies up to 18 GHz, and even 40 GHz, ensuring signal integrity and minimal loss in telemetry transmission.
- High-Density Design: The compact structure supports ultra-high mounting density, perfect for miniaturized radar and telemetry systems.
- Versatile Retention Options: Available in smooth bore, limited detent, and full detent interfaces, suitable for frequent mating cycles in test environments or vibration-resistant industrial applications.
- Durable Environmental Resistance: The rugged design withstands extreme temperature variations and intense vibration, ensuring stable performance in harsh electromagnetic and physical conditions.
- Flexible Mounting Solutions: Compatible with cable, flange, and through-hole PCB mounting, adaptable to various PCB layout requirements.
Our SMP connectors are the go-to solution for efficient and reliable interconnects in the most demanding modern electronic systems, from aerospace telemetry and phased array radar to high-end test and measurement equipment.
Technical Parameters:
| Impedance | 50 Ohm |
| Gender | SMP Female Connector |
| VSWR | <1.3 |
| Application | Satcom, 5G Base Station, Radar Detection & Telecommunication, 5G applications, Telemetry Equipment |
| Insulators | Glass |
| DWV | 500 VRMS |
| Frequency Range | DC ~ 40 GHz |
| Center Contact | Copper Alloy, Gold Plating |
| Housing Materials | Copper Alloy, Gold Plating |
| Mount | PCB Mount |
| Interface Form | Limited Detent |
Applications:
The Elite Electronics SMP RF Connector stands out as a trusted component for engineers and technicians working in Satcom, 5G Base Station, Radar Detection & Telecommunication, 5G applications, Telemetry Equipment.
Customization:
Elite Electronic offers customized solutions for our High Frequency SMP Coax Connector series. Our SMP Coax connectors, including SMP Female Coax Connector and SMP Male Coax Connector variants, are designed to operate efficiently in a frequency range of DC~40GHz, ensuring superior performance for your high-frequency applications.
Our products are certified with Rohs, ISO 9001, and 14001, reflecting our commitment to quality and environmental standards.
The minimum order quantity is 50pcs for our normal models; however, there is no MOQ restriction if the product is in stock.
We can supply our customization service according to the drawing.
MOQ for Customization: 200pcs
Packing & Shipping:
- Individual Anti-Static Packaging: Each connector is individually sealed in anti-static bags to prevent electrostatic damage.
- Custom Foam Inserts: Connectors are placed in custom foam inserts within sturdy cardboard boxes for enhanced shock and vibration protection.
- Reliable Courier Services: We use trusted couriers offering tracking and insurance, ensuring safe and timely delivery.
- Bulk Packaging for Multiple Connectors: Additional padding is used for bulk shipments to minimize movement and impact.
- Clear Labeling: Packages are clearly labeled with product information, handling instructions, and destination details for smooth customs clearance.
- Compliance with International Standards: Our packaging and shipping processes adhere to global standards, ensuring product integrity upon arrival.
FAQ:
Q1: What is the brand and model number of this SMP RF Coax Connector?
A1: The RF connector is branded ELT.
Q2: Where is the SMP RF Connector manufactured?
A2: It is manufactured in Xi'an, China.
Q3: What certifications does the Elite Electronic SMP RF Coax Connector have?
A3: The connector is certified with Rohs, ISO 9001, and ISO 14001.
Q4: What is the minimum order quantity and packaging details for this product?
A4: The minimum order quantity is 50 pieces, but there is no MOQ restriction if the item is in stock. The packaging includes 1 piece per plastic bag and 10 bags per carton.
Q5: What are the delivery time and payment terms for ordering the SMP RF Coax Connector?
A5: Delivery time is typically 5-7 working days for stocked quantities. Payment can be made via T/T or LC.
