TNC-SMA adapter TNC Socket to SMA Jack RF Coaxial Female to Male Connector Adapter

TYPE SMA is one kind of RF coaxial connectors that is widely applied, with small sized thread coupling. Characteristic impedance is 50ohm. The characteristic of connectors is in wide frequency range, excellent performance, high reliability. They are used in connection with RF cable or microstrip line in RF circuit of the WLAN system, controlled program, microwave equipment and the digital communication system.The frequency can be up to 18GHz by using semi-rigid or semi-flex cable.

TNC series product is designed as a threaded version of BNC connector, the TNC RF connectors features screw threads for mating.TNC connectors are miniature, threaded waterproof units with a constant 50ohm impedance,operating from DC-11GHz, there are two types of TNC connectors:standard and reverse polarity.these low cost connector typically utilize die cast and molded components.While performance will not be equal to the industrial or high quality grade products, these connectors are ideal for use on a varity of commercial applications

Specifiacation:

Detailed Drawing

There also have another type TNC MALE TO SMA MALE  RF adaptor can be choose:

Application:

- Wireless
- Antennas

- Broadband

- Instrumentation
- Phased array antennas

- Board-to-board interconnect

Between Series Adapter list:

NOTE:
We have over 10,000 types of Adapter, if the connector you are using is not found, please contact us with your details.
