316 Stainless Steel Flanged Globe Valve Multi Purpose For Pressure Reducing

Price Negotiable
Price: USD 50~500/set
MOQ: 1 set
Delivery Time: within 8-12 working days upon receipt of payment
Brand: SUFA
Product Description

Stainless Steel 316 API Rising Steam Globe Valve



Technical Specifications:

  • Design & Manufacture standard: DIN3356
  • Face to face dimension standard: DIN3202
  • Flange standard: DIN2543 to DIN2546
  • Test & Inspect: DIN3230
Material of main Parts Body Stainess Steel 304/304L/316/316L
Disc Stainless Steel 304/304L/316/316L
Stem Stainless Steel
Seat HF or STL
Backseat Bushing Stainless Steel
Packing Graphite+SS304/SS316
Bolt /Nut Stainless Steel
Operation Handwheel, Chain wheel, Gear Box, Pneumatic, Motor,Hydraulic
Working Temperature -196 to 425 Celsius degree
Working Medium Water, Oil, Gas, H2SO, Steam
