ADSS Fiber Optic Outdoor Cable， Multimode Fiber Optic Cable For FTTH
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
1 ~ 10 Working days based on the quantity
Brand:
JUNPU
Product Description
ADSS Fiber Optic Outdoor Cable, Multimode Fiber Optic Cable For FTTH
Characteristics:
- Good mechanical and temperature performance.
- PVC outer sheath and PE inner sheath make cable have a nice moisture resistance performance.
- Crush resistance and flexibility.
- Small cable diameter, light cable weight, easy to install.
- We can also provide OEM service, and packing as customer’s requirement.
| G.652 | G.655 | 50/125μm | 62.5/125μm | ||
Attenuation(+20℃) |
@850nm | ≤3.0dB/km | ≤3.3dB/km | ||
| @1300nm | ≤1.0dB/km | ≤1.0dB/km | |||
| @1310nm | ≤0.40dB/km | ||||
| @1550nm | ≤0.22dB/km | ≤0.23dB/km | |||
Bandwidth(Class A) |
@850nm | ≥500MHz·km | ≥200MHz·km | ||
| @1300nm | ≥1000MHz·km | ≥600MHz·km | |||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | |||
| Cable cut-off wavelength | ≤1260nm | ≤1450nm | |||
Application
- Adopted to Outdoor Aerial, Duct installation
Package
We sincerely invite you to send us inquiry for further details.
Junpu Cares About Every Single Details Of The Product For You !
Junpu Cares About Every Single Details Of The Product For You !
