Steam Methane Reforming Hydrogen Production Plant Purity Up To 99.999% (v/v)

What is Steam Methane Reforming Technology?

Steam methane reforming (or Steam Reforming) is a chemical reaction used to generate syngas (H2 and CO) from hydrocarbons such as natural gas. This is completed in a reformer which reacts methane with steam at high temperature and pressure along with nickel catalyst. Steam methane reformer is extensively used in industry to produce hydrogen.

Reaction Formula of SMR H2 Production

CH4+H2O→3H2+CO     -Q

CO+H2O→H2+CO2      +Q

Ally Hi-Tech‘s Achievements on SMR Technology

On the basis of the original synthetic ammonia gasification process, Ally Hi-Tech has carried out bold reforms on reforming furnaces, desulfurization conversion, transfer recovery systems, purification systems, etc., so that the investment in equipment is greatly reduced compared with the old technology, and the natural gas consumption is also reduced by about 1/3, especially In the technical transformation of the natural gas conversion core equipment-reformer, it has achieved breakthrough success and transformed the test on the already built equipment.

As for the aspect of technology innovation, natural gas conversion hydrogen production technology, our company applied for and obtained 6 national patents, and was supported by the Ministry of Science and Technology Innovation Fund.

In 2008, we provided the smallest 50Nm3 / h natural gas system for the Beijing Olympic Games.

Performance Index of Ally's SMR Hydrogen Production Plant

· Hydrogen Capacity: 50 ~ 50,000 Nm3/h

· Hydrogen Purity: 99% ~ 99.999% (v/v)

· Hydrogen Pressure: 1.3 ~ 3.0 MPa(G)

· Temperature: Ambient
