Electric Telescopic Boom Crane , Telescoping Crane Low Power Consumption
OUCO 4T30M Electric Hydraulic Telescopic Boom Marine Crane With ABS Class
Product Description
The telescopic series of cranes offer a diverse product line for application in the Luxury Yacht, Oceanographic, Workboat, Oilfield, Coast Guard or Military industries. These cranes can also be further customized for use in these most demanding of work environments.
All of the cranes in the Telescopic Boom line offer several key features that make them powerful solutions for the marine work environment. The most notable of these features include: Extended boom reach with the dexterity for accurate, safe, and efficient material handling.
Product Feature
1. Running smoothly.
2. Rates of speed can be changed.
3. 360 degrees continually rotary.
4. Both electro hydraulic and manual to control.
5. Operate conveniently.
6. Safety and reliability.
Technical Parameters
| SWL | 4T30M |
| Max. Working Radius | 30 m |
| Min. Working Radius | 3 m |
| Hoisting Speed | 0-15 m/min |
| Hoisting Height | 35 m |
| Slewing Speed | ~0.6 r/min |
| Slewing Angle | 360° |
| Luffing Time | ~90 s |
| Power Resource | AC380V/50HZ |
| Power | 90 kw |
| Elec-Motor Power | Y160L-4-H |
Genernal Arrangement
Product Details
FAQ
1. Q:Can this type work in hazardous environment?
A:Sure! We can customize for you, acid proof or explosion proof, no problem for that.
2. Q:Can you provide the serious lifting tools?
A:Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
3. Q:How can we install the crane?
A:Our senior engineer can be your side to do the installation guide service and training. Moreover, our best sales can visit your country.
4. Q:Safety device
A:Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
