4T30M Yacht Marine 12m/Min Telescopic Boom Crane
OUCO 4T30M Telescopic Boom Yacht Marine Crane For Sale
| Max. Lifting Moment(Ton.M) | 8 | 12 | 20 | 30 | 40 |
| Max. Lifting Capacity(Kg) | 1000 | 2000 | 4000 | 8000 | 10000 |
| Max. Working Radius(M) | 8 | 6 | 6.3 | 9.8 | 9.58 |
| Hydraulic Rated Pressure(Mpa) | 28 | 28 | 20 | 28 | 28 |
| Hydraulic Flow(L/Min) | 40 | 40 | 40 | 40 | 40 |
| Slewing Angle(°) | 360°Continuous | 360°Continuous | 400°Continuous | 360°Continuous | 360°Continuous |
| Slewing Speed | <2 | <2 | <2 | <2 | <2 |
| Recommended Power(Kw) | 20 | 20 | 18 | 22 | 30 |
| Installation Space(MM) | 1100 | 1000 | 1100 | 1200 | 1200 |
| Crane Self Weight(Kg) | 1080 | 920 | 1300 | 3400 | 3400 |
1. Compliance with the most demanding safety rules and regulations
2. Overload protection
3. Reliable long service life guaranteed through the use of high quality reputable components, extensive endurance testing and easy future upgrades
End User Advantages
1. Compact design with minimum height, width and length
2. Small footprint, for easy installation onboard
3. Delivered as one complete unit ready for installation to vessels
4. Easy access for periodic maintenance, service and repair, support by with clear labelling and detailed manuals
Jiangsu OUCO Heavy Industry And Technology Co.,Ltd
We are an integrated company of industry and trade,our factory specialize in this field for many years.Our factory can design andmanufacture any type marine/offshore cranes based on your technical requirements. To deliver the best possible products for the bestpossible price and quality. We are competitive as we have low labor cost, and deliver quality because we use Europeancomponentsin our cranes.Not only to deliver a good product, by experience we know that a crane is a one time investment for a client and howimportant it is to do repairs at location in a short time as most clients have to deal with a high day-rate from their vessels; “Down-time” is expensive. Do not be hesitate, please feel free to "SEND" inquiry to us.
FAQ
Q: What’s the capacity of your request crane?
A: From 0.5t to 100t.
Q: What’s working radius of your request crane?
A: From 1m to 100m.
Q: Which type of the crane should I choose?
A: Folding boom, knuckle boom, telescopic boom, stiff boom, etc. Some advices can be offered accordingly.
Q: Can this crane be explosion proof?
A: Sure, any extra function based on your requirement.
Q: Does your crane have safety devices?
A: Of course, all cut off limits and alarms for safety reasons.
Q: How can I install the crane to my vessel?
A: Our service engineers will go to the vessel site for guiding or ship the crane in whole piece.
Anything else? We will be pleased to answer all your questions and doubts.
